ABB 086339-001

Technical parameters

Input/output characteristics

Voltage: ABB 086339-001 supports wide range input (0-300V AC/DC), resolution of 0.1V (low range) to 1V (high range), accuracy ±0.5% reading ±4 digits.

Current: ABB 086339-001 supports 0-20A AC/DC, resolution 0.001A (low range), accuracy ±0.5% reading ±4 digits.

Power: range 200W-2000W, accuracy ±0.5% reading ±5 digits, frequency range 0-400Hz, power factor (PF) 0-1.

Communication interface: supports RS-232/485, Ethernet, PROFIBUS, EtherCAT and other protocols

Operating temperature: -25°C to +60°C

Principle of use

Power module function: ABB 086339-001 converts industrial power grid or intermediate bus voltage (such as 48V DC) into the voltage required by the equipment, supporting high power density conversion (such as 5W-20W/in³).

Sensor micro-intelligence: collect displacement, force and other signals through high-precision sensors, convert them into standard electrical signals, and output them to the control system after internal algorithm processing to achieve equipment status monitoring.

PLC control logic: receive sensor or host computer instructions, execute preset programs (such as motor start and stop, speed adjustment), and coordinate motor parameters (frequency, torque) through the inverter.

Industrial communication: ABB 086339-001 interacts with the host computer and distributed I/O modules through Ethernet or fieldbus protocols (such as Modbus to Profinet) to achieve centralized data management.
