Brand: ABB Description: Analog Output Module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 13 Payment Term: T/T Shipping Port: Shenzhen ABB AO815 3BSE052605R1 is an analog output module with HART transparent transmission function and integrated multiple self-diagnosis mechanisms to detect external power supply abnormalities, open circuits, short circuits and internal hardware failures.
|
Manufacture |
ABB |
|
Model Number |
AO815 |
|
Ordering Number |
3BSE052605R1 |
|
Country Of Origin |
Switzerland |
|
HS CODE |
85371000 |
|
Dimension |
5*10*12cm |
|
Packing Dimension |
7*12*14cm |
|
Weight |
0.5kg |
Number of channels: 8 independent output channels
Output type: 4~20mA current output, integrated HART communication protocol
Resolution: 12 bits
Working voltage: 24V DC
Output frequency: 50kHz
Communication interface: Support HART pass-through, compatible with Profibus DP-V1 module
Compatibility: Adapt to ABB S800 I/O series and AC 800M controller
Protection level: Anti-electromagnetic interference, working temperature range -25℃~+70℃
Redundancy support: Compatible with redundant power supply module and redundant I/O base
Signal load: Maximum load resistance 500Ω
Accuracy: ±0.05% full scale
Isolation voltage: Channel isolation 1500V AC
Power consumption: 3.5W
Functional features
1.High-precision multi-channel output
8-channel independent output design, each channel supports 4~20mA current signal, with a resolution of 12 bits, ensuring the precision control requirements of chemical, power and other scenarios
2.HART protocol deep integration
Built-in HART communication function, ABB AO815 3BSE052605R1 can directly interact with smart instruments, realize parameter configuration, status monitoring and diagnosis, and simplify the complexity of system integration
3. Modular redundant architecture
ABB AO815 3BSE052605R1 supports flexible combination with S800 series modules such as AI845 and DI840, and can be configured with redundant power supply and redundant I/O base to improve system reliability
4. Intelligent diagnosis and maintenance
Integrated real-time self-test function, ABB AO815 3BSE052605R1 can detect line disconnection, signal overrun and internal module faults, and alarm through the controller interface to shorten downtime maintenance time
5. Harsh environment adaptability
Adopts wide temperature design (-25℃~+70℃) and anti-vibration structure, suitable for harsh industrial environments such as petroleum and pharmaceuticals
Recommended supporting products
Controller: AC 800M series (such as PM861AK01)
Communication module: CI854AK01
Other I/O modules: AI810 (analog input), DI810 (digital input)
