Brand: ABB Description: Pulse Transformer Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 8 Payment Term: T/T Shipping Port: Shenzhen ABB DATX100 3ASC25H208 is designed for industrial automation systems and provides excellent input/output control performance. Its core function is to achieve precise signal conversion in digital control systems, especially suitable for scenarios requiring high precision. It adopts a compact design to optimize space utilization while ensuring high reliability and long service life, and is suitable for integration into all kinds of automation systems.
|
Manufacture |
ABB |
|
Model Number |
DATX100 |
|
Ordering Number |
3ASC25H208 |
|
Catalog |
- |
|
Country Of Origin |
Switzerland |
|
HS CODE |
8504319000 |
|
Dimension |
24*18*6cm |
|
Weight |
0.8kg |
Product Features
ABB DATX100 3ASC25H208 supports 16 independent channels and can handle signals of multiple voltage levels, suitable for complex industrial environments.
ABB DATX100 3ASC25H208 can convert signals with high precision to ensure the stability and accuracy of signal transmission and reduce signal distortion.
ABB DATX100 3ASC25H208 digital input/output supports 24V DC, analog input/output precision up to 12 bits, isolation voltage up to 500V AC, adapt to a variety of industrial standards.
ABB DATX100 3ASC25H208 pulse transformer operating frequency range of 10K-100kHz, significantly higher efficiency than traditional power transformers, smaller size.
ABB DATX100 3ASC25H208 durable design supports long-term stable operation and low maintenance cost, suitable for harsh industrial environments.
Product Using Principle
ABB DATX100 3ASC25H208 is based on the principle of electromagnetic induction, coupling the input PWM (Pulse Width Modulation) signal to the output terminal through the magnetic core to realize electrical isolation and signal conversion. The specific process is as follows:
The input DC voltage is converted into a high-frequency PWM signal by the control circuit.
The high-frequency signal is converted to voltage by a pulse transformer, and the core material is used to optimize magnetic permeability and efficiency.
The output high-frequency pulse signal is rectified and filtered, and then converted to a stable DC voltage for use in subsequent circuits.
Product Application
In industrial automation, ABB DATX100 can be used for robot control, production line equipment monitoring, realizing high-precision signal transmission and isolation.
ABB DATX100 can be used for signal isolation and conversion in power distribution networks to ensure grid stability.
ABB DATX100 can be used in the control circuits of solar inverters, wind turbines and other equipment to process high-frequency pulse signals.
ABB DATX100 can be used with drivers to realize precise speed regulation and protection of motors and reduce electromagnetic interference.
