ABB DSDP140A

Working Parameters

Typical Input Voltage: ABB DSDP140A usually has an input voltage of 24V DC, which can provide a constant energy supply for its internal parts.

Output Voltage: The output voltage is 5V DC, which helps to power other connected devices or components in the system.

AO Resolution: The analog output (AO) is a symbol with 11-bit resolution and an output range of 0 to 10V or 0 to ±20mA.

Output Frequency: 30kHz.

Product Function

Data Acquisition and Pulse Counting: The NPN Pulse Counter Board DSDP140A is used to count external pulses. This technology counts only the rising edge of the input and represents the frequency of the signal to achieve high-precision counting and measurement of high-speed pulse signals, providing a basis for subsequent (2nd, 3rd, etc.) analysis and control.

Versatile and Flexible: It supports multiple modes for different types of rotary encoders and has a wide range of processing, which can be used in many applications. This flexibility enables it to be easily plugged into existing systems.

High reliability: ABB DSDP140A is designed with quality in mind, using durable components to ensure a long service life. It has a low failure rate, minimizing maintenance needs and downtime, which makes sense for continuous industrial operations.

Scalability: ABB DSDP140A has strong scalability and can support serial and parallel use of multiple pulse counter boards. This allows users to cluster the system according to their specific needs, providing users with greater flexibility for future upgrades and expansions.

Diagnostic and indication functions: It has internal module diagnostic functions to monitor the operating status of the device. In this enhanced version, it has LED indicators to indicate the status of each input, output, and there are also three status LEDs, which helps to quickly troubleshoot and monitor the system.

Application range

Manufacturing: Used to count and monitor the rotation of motors, conveyor belts and other mechanical elements in production lines. This helps to accurately fine-tune all production processes, thereby improving product quality and production efficiency.

Industrial process control: ABB DSDP140A can be used in industries such as chemical, pharmaceutical, food and beverage to monitor and control flow, level or other industrial parameters by counting pulses received from flow meters, level sensors or other types of measuring devices.

Metallurgy and mining: It can be used in these industries to control the operation of crushers, conveyors, etc. and provide accurate data for process optimization and machinery maintenance.

Automotive manufacturing: It is used to count produced parts on automotive production lines, monitor the rotation of robotic arms, and control the movement of lifting conveyor systems.

Power generation and distribution: ABB DSDP140A can monitor the speed of turbines, generators and other rotating equipment in power plants to ensure safe and efficient operation of power generation systems.
