Brand: ABB Description: Output Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 4 Payment Term: T/T Shipping Port: Shenzhen ABB DSTDW150 57160001-AAK is used in converting digital signals received from controllers into physical outputs capable of driving relays, solenoid valves, and motors. It has been designed with the intention of achieving high reliability, fast response together with flexible configuration options, therefore making it appropriate for automated scenarios where precise control is a requirement.
|
Manufacture |
ABB |
|
Model Number |
DSTDW150 |
|
Ordering Number |
57160001-AAK |
|
Catalog |
- |
|
Country Of Origin |
Switzerland |
|
HS CODE |
8538900000 |
|
Dimension |
34*24*20cm |
|
Weight |
0.8kg |
Product Features
ABB DSTDW150 57160001-AAK supports 16 independent output channels, enabling simultaneous control of multiple devices and enhancing the system's parallel processing capabilities.
ABB DSTDW150 57160001-AAK uses industrial-grade components, offering electromagnetic interference (EMI) resistance and wide temperature operating capabilities, making it suitable for harsh environments (such as -20°C to +60°C).
ABB DSTDW150 57160001-AAK supports relay outputs, such as 0-240V AC/DC, with a maximum load of DC 48W/AC 720VA, or transistor outputs, to meet the needs of different actuators.
ABB DSTDW150 57160001-AAK integrates overcurrent, overvoltage, and overheat protection to prevent equipment damage and ensure safe system operation.
ABB DSTDW150 57160001-AAK supports hot-swapping and plug-and-play functionality, simplifying maintenance processes and reducing downtime.
Product Using Principle
ABB DSTDW150 57160001-AAK receives digital commands (such as 0/1 signals) from a PLC or controller via a backplane bus or communication interface.
Its internal circuitry converts the digital signals into drive voltage/current, triggering the closure of relay contacts or the conduction of transistors.
Its output signals directly drive external devices, enabling automated control of production processes.
Some models support output status monitoring, providing feedback on the current channel status via LED indicator lights or communication interfaces.
Product Parameter
The following detail is for ABB DSTDW150 57160001-AAK.
|
Parameter |
Typical Value / Range |
|
Output Type |
Relay output (or transistor output) |
|
Number of Channels |
16 channels |
|
Operating Voltage |
DC 24V ±20% |
|
Maximum Load Current |
3A per channel (relay) |
|
Response Time |
<10ms |
|
Protection Class |
IP20 (for indoor installation) |
|
Communication Protocol |
Supports Modbus, Profibus, etc. (to be confirmed) |
|
Operating Temperature |
-20°C to +60°C |
|
Mounting Method |
DIN Rail mounting |
