Brand: ABB Description: Analog Input Module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 4 Payment Term: T/T Shipping Port: Shenzhen ABB IMFEC12 is mainly used to convert analog signals from field sensors into digital signals for real-time processing and analysis by controllers. The module supports multiple industrial standard signal types and features high precision, high reliability, and flexible configuration capabilities. It is widely used in process control, environmental monitoring, power systems, and other fields.
|
Manufacture |
ABB |
|
Model Number |
IMFEC12 |
|
Ordering Number |
IMFEC12 |
|
Catalog |
- |
|
Country Of Origin |
Switzerland |
|
HS CODE |
8473309000 |
|
Dimension |
12*8*4cm |
|
Weight |
0.4kg |
Product Features
ABB IMFEC12 supports ±0.1% full-scale accuracy and 16-bit resolution, enabling precise capture of even the smallest signal changes.
ABB IMFEC12 features built-in digital filtering functionality to effectively suppress high-frequency noise and ensure signal stability.
ABB IMFEC12 supports current signals from -20mA to +20mA (compatible with the 4-20mA standard). It supports voltage signals such as 0-10V, ±5V, and ±10V (configuration via jumpers is required).
ABB IMFEC12 integrates a microprocessor, A/D converter, and communication circuitry, enabling independent signal conditioning, calibration, and diagnostics.
ABB IMFEC12 supports self-diagnostic functionality, continuously monitoring module status and automatically triggering alarms in case of faults.
ABB IMFEC12 allows input type (current/voltage), filtering time, and signal calibration parameters to be configured via DIP switches or software.
ABB IMFEC12 supports multiple wiring configurations, enabling direct connection to transmitters or connection via terminal units.
ABB IMFEC12 features electrical isolation between channels, offering strong interference resistance, making it suitable for complex industrial electromagnetic environments and meeting the demands of harsh industrial conditions.
Product Using Principle
ABB IMFEC12 connects to field transmitters via terminals or cables to receive analog current or voltage signals.
The signal is divided and filtered before entering the A/D converter, where it is converted into a 16-bit digital value (range: -32768 to +32767).
The microprocessor performs linearization, range conversion, and fault diagnosis on the digital signal. The processed data is transmitted via a dedicated bus to a multifunction processor or controller for real-time monitoring and regulation by the control system.
It supports software calibration (via the ABB Composer tool) or hardware jumper settings for input type and filtering parameters.
It allows selection of the transmitter power supply mode (external power supply or internal module power supply) via DIP switches.
Product Application
ABB IMFEC12 can be used in the chemical and petrochemical industries to monitor reactor pressure, temperature, and fluid flow.
It can be used in food and beverage production lines to monitor filling pressure, liquid level, and environmental temperature and humidity.
It can be used in power plant turbine DEH systems to collect steam pressure and flow signals, enabling speed and power control.
It can be used in substations to monitor busbar voltage, current, and equipment temperature, ensuring grid stability.
It can be used in wastewater treatment plants to monitor water quality parameters (pH value, turbidity, dissolved oxygen). Environmental monitoring stations collect atmospheric pollutant concentrations (such as SO₂, NOx).
It can be used in CNC machine tools to monitor spindle load current and feed speed in real time, optimizing machining accuracy.
It can be used for condition monitoring and energy efficiency management of equipment such as compressors and fans.
