ABB NKLS01-L15

Technical Parameters

Rated insulation voltage: 690V AC

Rated operating voltage: 230-400V AC

Control circuit voltage: 24V DC

Rated current: 15A

Operating temperature: -25°C to +60°C

Storage temperature: -40°C to +80°C

Ambient humidity: ≤85% RH

Function Features

Transmission: ABB NKLS01-L15 Reliable signal transmission features In DCS, it is a key component that connects the network interface slave module (INNIS01) and the terminal cable (NKLS01/11), enabling the smoothest communication in the Infi-Net ring. It is essential for the integrity of control commands and sensor data transmission.

Compatibility: In response to the needs of different customers, ABB NKLS01-L15 supports multiple communication interfaces and multiple common industrial communication protocols, such as serial communication, Ethernet communication, etc. The strong communication protocol compatibility allows it to seamlessly connect and communicate well with various brands and types of equipment and systems. In the construction of such a large industrial automation network, it can be used as a connection hub to enable scattered equipment to work together, break information islands, realize rapid data transmission and sharing, and greatly improve the integrated coordination efficiency of the entire industrial system, which meets the development needs of modern industrial intelligence and information.

Quality: ABB NKLS01-L15 is durable and made of high-grade materials to perform best in industrial conditions. It resists environmental factors such as humidity, dust and temperature changes, so it can operate for a long time without the need to replace the product.

Application areas

Industrial Automation:ABB NKLS01-L15 In the factory production line control system, a real-time database is used as a link between different devices and the central control unit to ensure timely and correct data transmission. For example, whether it is the specific action instructions of the robot arm or the feedback of various sensor data on the production line, it can work very stably to ensure the orderly production process, greatly improve production efficiency, and reduce production shutdowns caused by communication barriers.

Application in power plants:ABB NKLS01-L15 can timely collect operating parameters of equipment such as generator sets and transformers, such as voltage, current, temperature, etc., and transmit them to the monitoring center in a timely manner. When the equipment is abnormal, the system can quickly alarm, and the staff can query the repaired faults based on the data to ensure stable power supply, reduce the risk of power outages, and provide reliable energy guarantees for social production and life.

Smart building field: ABB NKLS01-L15 makes building automation management lively and can link the building's lighting system, air conditioning system, security system and other systems to achieve information sharing and collaborative work between systems. For example, by integrating with environmental sensors, smart lighting can automatically adjust the brightness of objects and the temperature of air conditioners according to changes in incoming and outgoing light and temperature, achieving the dual effects of energy saving and comfort. At the same time, in terms of security, smart lighting integrates data from access control devices, cameras, etc. to improve building security and management efficiency, providing users with a convenient and intelligent working and living environment.
