Brand: ABB Description: Processor Unit Condition: Brand New Certificate：COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 8 Payment Term: T/T Shipping Port: ShenZhen ABB PM866AK01 3BSE076939R1 which is a processor unit comes with a 133MHz processor and 64 MB of memory suitable for complex control algorithms and data processing and could be easily connected to other devices and systems.
|
Manufacture |
ABB |
|
Model Number |
PM866AK01 |
|
Ordering Number |
3BSE076939R1 |
|
Catalog |
AC 800M |
|
Country Of Origin |
Sweden |
|
HS CODE |
8538900000 |
|
Dimension |
20cm*15cm*12cm |
|
Packing Dimension |
22cm*17cm*14cm |
|
Weight |
1.5kg |
Hardware Configuration
Processor: MPC866 @ 133MHz
Memory: 64MB RAM (51.389MB available to users)
Storage: 4MB Flash (firmware storage)
Real-time clock: Accuracy ±100 ppm (approximately ±1 hour/year)
Communication interface
Ethernet: 2×RJ45 ports (10 Mbit/s), supports redundant communication.
Serial port:
COM3: RS-232C (75-19,200 baud, non-isolated, supports RTS/CTS).
COM4: RS-232C (9,600 baud, opto-isolated, for configuration tools).
Performance and expansion
Calculation speed: 0.09 ms/1000 Boolean instructions.
Expansion capability
ABB PM866AK01 supports up to 12 communication modules (CEX bus).
A single machine supports up to 96 I/O modules (84 in redundant configuration).
Redundancy support: CPU redundancy can be achieved through options (requires BC810/BC820).
Functional Features
User Friendly: ABB PM866AK01 3BSE076939R1 uses a patented sliding and locking method for fast DIN rail installation and removal. Its modular design allows for easy replacement of parts, which lowers maintenance costs and time.
CPU Redundancy Support: ABB PM866AK01 3BSE076939R1 achieves high availability for critical applications, allowing the system to continue running even if the CPU fails.
High Computing Power: Built-in 133MHz MPC866 processor can quickly execute complex control algorithms and handle many data processing tasks, more than 1000 Boolean operations only takes 0.09 ms.
Rich Communication Interfaces: 2x RJ45 Ethernet, 2x RJ45 serial. ABB PM866AK01 allows user to connect other devices and elements such as sensors and actuators, as well as to exchange and communicate data, using different protocols.
Confident Expand ability: Up to 96 I/O modules can be supported, and the module bus scan speed can be adjusted from 0 to 100 ms, users can configure and expand according to their own actual needs.
Application Areas
Industrial Automation: ABB PM866AK01 3BSE076939R1 is widely Used in Production Lines. For example, in automotive manufacturing, electronics manufacturing, etc. Control the operation of conveyors, robs and other equipment, improve production efficiency and product quality.
Power Sector: It is used to monitor and control the operation of generators, transformers and circuit breakers in power generation, transmission and distribution systems, ensuring the stable operation of the power grid.
Chemical industry: ABB PM866AK01 3BSE076939R1 is used to control temperature, pressure, flow and other parameters of reactors, distillation towers and other equipment in chemical production processes to ensure the safety and stability of production processes.
Water Treatment: This module can be applied to water treatment plants to control the operation of water treatment equipment such as pumps, valves and filters, and automatically control the water treatment process of water purification, sewage treatment, etc.
Building Automation: ABB PM866AK01 3BSE076939R1 can be utilized in smart buildings to manage lighting systems, air conditioning systems and elevator systems and enhance the comfort and energy efficiency of buildings.
