ABB TB805

Details

1. Functional parameters

Power supply voltage: generally 220V AC, the module works continuously within the voltage variation range to ensure the stable power supply conditions required for normal operation.

Output frequency: 50Hz, in line with the normal power supply frequency of electrical equipment, ensuring that the application works at normal frequency and meets the power supply frequency requirements of other electrical equipment.

Environmental adaptability: The operating temperature range is 0-55℃; the storage temperature is -25 to +70℃; the humidity is 5-95% (no condensation). TB805 has good environmental adaptability and can work stably in various industrial environments.

Protection level: IP20, which can prevent foreign objects from intruding and prevent external objects from damaging any internal devices.

2. Function

Bus extension function: ABB TB805 is a module bus cable adapter, usually used with TB806 and TK801v0xx, with an additional module positioning bus, so that I/O modules on the same electrical kitchen bus can be separated from different DIN rails to simplify layout work and system expansion, and improve the flexibility and scalability of the entire system.

Signal transmission/conversion function: ABB TB805 accepts precise transmission and conversion of signals with the required efficiency to ensure that data can be successfully exchanged between all devices/systems. In industrial automation control systems and related environments, various sensors, actuators and devices can be connected to the control system, facilitating comprehensive monitoring and control of the production process.

Compatibility and versatility: TB805 has high compatibility and can be applied to various processes of process controllers from suppliers such as ABB. It is able to seamlessly connect with other devices and systems to achieve data sharing and work together, providing a simpler and cheaper system integration method.

3. Application fields

Industrial field: TB805 is widely used in industrial automation production lines in various industries such as packaging machinery, plastic machinery, printing and dyeing, printing and pressing, lifting machinery, etc., to achieve precise control and monitoring of production machines, thereby improving production efficiency and product quality.

Energy industry: ABB TB805 can monitor and control energy equipment in energy optimization, wind power generation systems, petrochemicals, steel and metallurgy industries, etc., to achieve reasonable allocation and utilization of energy, and reduce energy consumption and production costs.

Smart building: ABB TB805 is suitable for air conditioning and refrigeration systems, HVAC systems, etc., to achieve remote automatic adjustment of environmental parameters and equipment, and improve the comfort and energy saving effect of buildings.

Municipal engineering: From municipal pumping stations to municipal engineering and environmental protection, all related equipment is controlled and monitored through various sensors to ensure the normal operation and maintenance of municipal facilities and improve the management level of urban infrastructure.
