ABB TB820V2

1. Technical Parameter

Power Supply Voltage: 24V.

Typical Power Consumption: 100mA.

Communication Protocol: Module Bus.

Interface: 1 electrical interface, 2 fiber optic ports.

Operating Temperature: 0 to +55°C.

Storage Temperature: -40 to +70°C.

Relative Humidity: 5% - 95%, non-condensing.

Pollution Degree: Degree 2, IEC 60664-1.

Corrosion Protection: ISA-S71.04: G3.

Protection Class: IP20.

2. Functional Features

Supervisory Function：As part of its supervisory function, ABB TB820V2 can also monitor the I/O module bus and power supply, keeping the system's operation in a stable state and able to detect when things go awry, and raise the alarm in due time.

Flexible Cluster Configuration: Flexible cluster number from 1 to 7 across the optical module bus with rotary switch on the back allowing for more diverse setup for different network topologies.

Isolation Power Supply: ABB TB820V2 provides isolated power supply to I/O modules, enhancing the anti-interference ability of the system and the stability of power supply.

Dual interface: The power of a logically identical bus with electrical and optical interfaces, for example up to 12 I/O modules can be connected to the electrical module bus and up to seven clusters can be connected to the optical module bus.

3. Fault Diagnosis

Communication Failure: Verify the connection and damage of the fiber optic cable of ABB TB820V2. Verify if the communication protocol settings are accurate and if there is electromagnetic interference causing issues with communication.

Power Failure: Check if the 24V power supply voltage is normal and the power supply circuit is open or short circuit.

Module Detection Error：Ensure ABB TB820V2 connected to the module bus are installed and working. Check if the module address settings are correct and if the TB820V2 rotary switch is properly set.

4. Application Areas

Industrial Automation: It is used to link multiple controllers, sensors and actuators to ensure accurate control and supervision for production lines in automotive and electronics industries.

Process Control: In the petrochemical, power, and water treatment industries, ABB TB820V2 is used to create communication networks of distributed I/O systems (i.e., those used in process control) that allow real-time monitoring and control of process parameters.

Building Automation: It is utilized for IoT-based smart building systems to integrate devices such as lighting, air conditioning, and security systems for centralized monitoring and management.

Energy Management Systems: In energy management systems of factories and commercial buildings, ABB TB820V2 assists in monitoring and controlling equipment that consumes energy for energy optimization and energy management.
