Brand: ABB Description: Exteded I/O Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 4 Payment Term: T/T Shipping Port: Shenzhen ABB YPQ110A processes and analyzes the collected digital and analog signals, generates corresponding control signals according to the preset control logic and algorithms, and sends them to the actuating elements or other devices through the communication interface or output channel to realize the control of motors or other devices.
|
Manufacture |
ABB |
|
Model Number |
YPQ110A |
|
Ordering Number |
YPQ110A |
|
Catalog |
ACS 500 |
|
Country Of Origin |
Switzerland |
|
HS CODE |
9032900090 |
|
Dimension |
18*18*8cm |
|
Weight |
0.6kg |
Product Features
ABB YPQ110A is capable of handling digital and analog signal input and output, integrating digital input, digital output and analog input, etc. It can collect digital and analog signals from the field, such as switching status, temperature, pressure, etc., and control the execution elements, such as motors and valves.
ABB YPQ110A can conveniently configure module parameters through software tools according to different application requirements, adapting to complex control systems and different application requirements.
ABB YPQ110A supports a variety of communication protocols, such as Modbus TCP/IP, CANopen, etc., which facilitates data exchange and communication with other devices or systems.
ABB YPQ110A is equipped with fault detection function, which can provide diagnostic information to monitor the system status and ensure the stable operation of the system.
ABB YPQ110A adopts industrial-grade components, adapts to the harsh industrial environment, integrates various I/O functions, saves space and improves system reliability.
Product Using Principle
ABB YPQ110A integrates a high-precision analog-to-digital converter module, supporting ±10V analog input and 0-20mA current input, with a resolution of up to 12-bit (LSB=2.44mV) and linearity error control within ±0.1% FS.
ABB YPQ110A adopts 32-bit ARM Cortex-M4 processor with 168MHz main frequency and built-in floating-point operation unit to realize real-time processing of complex algorithms.
ABB YPQ110A adopts AgSnO₂ contact material for the relay output channel, with a breaking capacity of 40A (AC-3 category), and supports hot-swap replacement, which is suitable for industrial equipment with frequent starting and stopping.
ABB YPQ110A adopts PID algorithm with sampling frequency of 10kHz to dynamically adjust the motor current. It supports fuzzy PID algorithm and automatically adjusts parameters according to load changes.
Product Application
In the synchronous generator system, ABB YPQ110A regulates the excitation current through the thyristor trigger module, with a trigger angle accuracy of ±0.5°, which can control the generator terminal voltage fluctuation within ±1%.
ABB YPQ110A collects indoor temperature and humidity signals through analog inputs, combines with CO₂ concentration sensor data, and adopts the fuzzy PID algorithm to adjust the frequency of air conditioner inverter, which reduces energy consumption by 20%.
ABB YPQ110A detects the infrared signal of human body through digital input, combines with the data of illumination sensor, and dynamically adjusts the LED driving current to realize on-demand lighting.
In the automotive welding production line, ABB YPQ110A communicates with the 6-axis robot controller via CANopen to synchronize the position commands in real time (cycle time of 1ms), and at the same time controls the welding torch current via analog output, which improves the qualified rate of welding quality to 99.8%.
