Brand: Bently Nevada Description: 114M5329-01 Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 9 Payment Term: T/T Shipping Port: Shenzhen Bently Nevada 114M5329-01 The 114M5329-01 HV-PIM is used in Bently Nevada 3500 and 3700 Series rack systems to generate and distribute high-voltage DC rails required by proximity probe preamplifiers, certain barrier networks, and high-impedance sensor isolators.
|
Manufacture |
Bently Nevada |
|
Model Number |
114M5329-01 |
|
Ordering Number |
114M5329-01 |
|
Catalog |
3500/15 |
|
Description |
High Voltage DC Power Supply |
|
Country Of Origin |
USA |
|
HS CODE |
8473309000 |
|
Dimension |
12*5.8*25 (CM) |
|
Weight |
1.4 kg |
Technical Parameters
Input Voltage: 18–32 V DC via rack backplane (nominal 24 V DC) for Bently Nevada 114M5329-01
Output Voltage: +350 V DC nominal (adjustable ±10 % via front-panel potentiometer)
Maximum Load Current: 30 mA per rail (single-output design) in Bently Nevada 114M5329-01
Regulation: ±5 % over full load and input-voltage variation
Ripple & Noise: ≤ 200 mV p-p (bandwidth 0–10 kHz)
Isolation:
Input-to-output: 3 kV DC for Bently Nevada 114M5329-01
Output-to-chassis: 1.5 kV DC
Protections:
Overcurrent shutdown with auto-retry
Thermal-shutdown guard with auto-reset
Reverse-polarity input protection
Efficiency: ≥ 85 % typical at 50 % load
Indicators: Front-panel LEDs for “HV OK” and “Fault”
Operating Environment:
Temp: –20 °C to +65 °C
Humidity: 0–95 % RH, non-condensing
Product function
Converts rack DC power into regulated +350 V DC via Bently Nevada 114M5329-01 for high-voltage sensor preamplifiers or barrier networks. Continuously monitors output health and reports faults to the system interface.
Application Areas
Proximity Probe Preamplifiers: Supplying high-voltage excitation using Bently Nevada 114M5329-01 for 3300 XL cables in long runs.
Intrinsic-Safety Barriers: Driving zener-barrier networks requiring elevated DC rails.
High-Impedance Sensor Isolators: Powering specialty isolators demanding HV inputs.
Retrofit and Test Racks: Integrating legacy HV devices with Bently Nevada 114M5329-01 without external supplies.
