Brand: Bently Nevada Description: Velomitor CT Velocity Transducer Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 10 Payment Term: T/T Shipping Port: Shenzhen The Bently Nevada 190501-12-00-CN is an industrial-grade extension cable, part of the Bently Nevada monitoring system. It connects the 3300 series eddy current probe to the preamplifier, allowing the impedance signal sensed by the probe to be transmitted without distortion over short and medium distances.
|
Manufacture |
Bently Nevada |
|
Model Number |
190501-12-00-CN |
|
Ordering Number |
190501-12-00-CN |
|
Catalog |
1905 |
|
Country Of Origin |
America |
|
HS CODE |
8543709990 |
|
Dimension |
12*12*3CM |
|
Packing Dimension |
15*15*5CM |
|
Weight |
0.5kg |
Electrical Performance
Sensitivity: 3.94 mV/mm/s (100 mV/in/s) ±5%.
Frequency Response: 3.0 Hz to 900 Hz (±1.0 dB), extended to 1.5 Hz to 1.0 kHz.
Velocity Range: 63.5 mm/s peak (2.5 in/s peak).
Output Bias Voltage: 10.1 Vdc ±1.0 Vdc.
Dynamic Output Impedance: <400 Ω.
Noise Floor: 0.229 mm/s peak.
Environmental
Operating Temperature: -40°C to +85°C (-40°F to +185°F), Storage Temperature: -40°C to +100°C.
Shock: 5000 g peak, maximum.
Humidity: 100% condensing (non-submerged). Magnetic field sensitivity: <0.0068 mm/s/gauss (@ 50 gauss, 50-60 Hz)
Performance Specifications
Lateral Response: <5% axial sensitivity.
Amplitude Linearity: ±2% to 63.5 mm/s peak.
Mounted Resonant Frequency: Minimum 9 kHz.
Product Advantages
Bently Nevada 190501-12-00-CN have strong anti-interference capability, the high-density copper mesh shield effectively isolates electromagnetic interference in industrial environments.
Bently Nevada 190501-12-00-CN have excellent weather resistance, the fluoroplastic insulation and PA outer sheath are resistant to high and low temperatures and oil stains, making them suitable for harsh operating conditions such as power plants and petrochemicals.
Application
Bently Nevada 190501-12-00-CN can be used in the power industry, petrochemical industry, metallurgy industry, energy industry.
Accessories and Ordering Information
For the Bently Nevada 190501-12-00-CN configuration (AA=12, BB=00, CC=CN), recommended accessories include:
Mounting Adapter: AA=12 corresponds to "Plate Stud 3/8-in 24 to M8x1," spare part number 125094-01.
Cable: BB=00 uses a MIL-C-5015 connector; the CB2W100-AAA series is recommended. For example:
0.32 ft cable: part number CB2W100-032.
Other Accessories:
Conduit Adapter: 128608-02 (1/2-in NPT).
Adhesive Mount Kit: 04284020-01.
Compression Fitting: 03850000.
Ordering Tips:
Complete Model Number: 190501-12-00-CN. Armor or conduit: Available in 106924-AA (Teflon-coated armor) or 14847-AA (flexible metal conduit).
Note
Compatibility: The Bently Nevada 190501-12-00-CN compatible only with Bently Nevada 3300 series probes and preamplifiers of the same brand. Do not use components from other brands.
Extra-distance/Modification: Do not cut or splice the probes for extension. Do not replace connectors or remove the shielding layer without authorization.
