Brand: Bently Nevada Description: Reverse Mount Probe Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 10 Payment Term: T/T Shipping Port: Shenzhen The Bently Nevada 330105-02-12-10-02-05 is a 3300 XL 8mm reverse-mount probe designed for monitoring the operating status of industrial equipment. It features a 3/8-24 UNF thread for easy installation and precise measurement of vibration, displacement, and other parameters at critical equipment locations.
|
Manufacture |
Bently Nevada |
|
Model Number |
330105-02-12-10-02-05 |
|
Ordering Number |
330105-02-12-10-02-05 |
|
Catalog |
3300XL |
|
Country Of Origin |
America |
|
HS CODE |
9031900090 |
|
Dimension |
30*30*4CM |
|
Packing Dimension |
32*32*6CM |
|
Weight |
1.15 kg |
Product Overview
Model: 330105-02-12-10-02-05
Type: 3300 XL 8mm Reverse Mount Probe
Mounting Thread: 3/8-24 UNF
Total Length: 1.0 m
Connector Type: Micro Click Loc Coaxial Connector
Linear Range: 2 mm (80 mils)
Sensitivity: 7.87 V/mm (200 mV/mil)
Frequency Response: 0 - 10 kHz
Operating Temperature: Standard: -52°C to +177°C, High Temperature Probe: -52°C to +218°C
Minimum Target Size: 15.2 mm (0.6 in) diameter (flat target)
Product Features
Accurate Measurement: Bently Nevada 330105-02-12-10-02-05 based on eddy current principles, it precisely measures static displacement and dynamic vibration, providing reliable data for equipment health assessment.
Easy Installation: Bently Nevada 330105-02-12-10-02-05 with the standard 3/8 - 24 UNF thread design, coupled with a micro Click Loc coaxial connector, allows for simple and efficient installation.
Excellent Compatibility: About Bently Nevada 330105-02-12-10-02-05, all 3300 XL 8mm eddy current sensor system probes, extension cables, and proximitor sensors are interchangeable.
Applications
Power Industry: Bently Nevada 330105-02-12-10-02-05 used for vibration and displacement monitoring of equipment such as steam turbines and generators, promptly detecting problems such as loose components and wear.
Petrochemical Industry: Bently Nevada 330105-02-12-10-02-05 suitable for equipment such as compressors and pumps, accurately measuring vibration and displacement parameters to provide real-time visibility into equipment operating status.
Compatibility
Component Interchangeability: Electrically and physically compatible with all 3300 XL and non-XL 5 mm/8 mm probes, extension cables, and Proximitor sensors. For example:
Can be paired with a 3300 XL Proximitor sensor (such as the 330180 series).
Extension cables must match the total system length (e.g., a 1.0 m probe with a 4.0 m extension cable for a 5 m system).
Performance Limitations: When mixing XL and non-XL components, system performance is limited to the non-XL specifications.
