Brand: Bently Nevada Description: 330180-51-05 Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 13 Payment Term: T/T Shipping Port: Shenzhen Bently Nevada 330180-51-05 Transduces minute variations in the air gap between the sensor tip and a rotating steel target into a proportional AC voltage.
|
Manufacture |
Bently Nevada |
|
Model Number |
330180-51-05 |
|
Ordering Number |
330180-51-05 |
|
Catalog |
3300 XL |
|
Description |
Proximitor Sensor |
|
Country Of Origin |
USA |
|
HS CODE |
85389091 |
|
Dimension |
16*16*12 (CM) |
|
Weight |
1.6 kg |
330180-AA-BB
A: Total Length and Mounting Option
10 1.0 meter (3.3 feet) system length, panel mount
11 1.0 meter (3.3 feet) system length, DIN mount
12 1.0 meter (3.3 feet) system length, no mounting hardware
50 5.0 meters (16.4 feet) system length, panel mount
51 5.0 meters (16.4 feet) system length, DIN mount
52 5.0 meters (16.4 feet) system length, no mounting hardware
90 9.0 meters (29.5 feet) system length, panel mount
91 9.0 meters (29.5 feet) system length, DIN mount
92 9.0 meters (29.5 feet) system length, no mounting hardware
B: Agency Approval Option
00 Not required
05 CSA, ATEX, IECEx Approvals
Technical Parameters
Channels: 6 isolated analog inputs in Bently Nevada 330180-51-05
Input Range: 4–20 mA (internally terminated at 250 Ω) or –10 V to +10 V
Accuracy: ±0.25 % of full scale
Repeatability: ±0.1 % of full scale
Isolation Voltage: 500 V channel to chassis
Noise Immunity: 500 mV peak differential
Transient Immunity: 10 kV burst per IEC standards
Conversion Rate: 10 samples/sec per channel
Power Consumption: 7 W typical
Operating Temp: 0 °C to +70 °C
Storage Temp: –40 °C to +85 °C
Humidity: Up to 95 % RH, non condensing
Product function
Loop Conditioning: Buffers and linearizes 4–20 mA or ±10 V loops via Bently Nevada 330180-51-05, applying precise 250 Ω terminations.
Digitization: Converts analog inputs to digital values for transmission over the 3500 backplane bus.
Alarm Logic: Compares each channel against programmable high/low setpoints and flags alarm conditions.
Diagnostics: Detects open circuit, short circuit, overrange, and reports faults to the system interface.
Isolation: Provides galvanic isolation to prevent ground loops and protect downstream electronics.
Application Areas
Process Monitoring: Pressure, flow, temperature, and level loops using Bently Nevada 330180-51-05 in turbines, compressors, pumps, and engines.
Machine Protection: Feeding safety critical alarms (overpressure, overtemperature) into trip logic.
DCS/SCADA Integration: Converting field loops into digital data with Bently Nevada 330180-51-05 for plant control systems.
Hazardous Area Panels: Zone 2/Div 2 installations where internal module isolation replaces external barrier hardware.
Retrofit Projects: Upgrading analog racks using Bently Nevada 330180-51-05 while retaining existing sensor loops.
