Brand: Bently Nevada Description: 3500/15-04-04-00 Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 12 Payment Term: T/T Shipping Port: Shenzhen Bently Nevada 3500/15-04-04-00 Provides centralized DC power conditioning and distribution for Bently Nevada 3500 Series rack systems.
|
Manufacture |
Bently Nevada |
|
Model Number |
3500/15-04-04-00 |
|
Ordering Number |
3500/15-04-04-00 |
|
Catalog |
3500/15 |
|
Description |
Low Voltage DC |
|
Country Of Origin |
USA |
|
HS CODE |
7326909000 |
|
Dimension |
12*5.8*25 (CM) |
|
Weight |
1.4 kg |
Ordering Information
3500/15-AXX-BXX-CXX
A: Power Supply Type (Top Slot)
01 Low Voltage ac (85 to 132 Vac rms)
02 High Voltage ac (175 to 264 Vac rms)
03 High Voltage dc (88 to 140 Vdc)
04 Low Voltage dc (20 to 30 Vdc)
B: Power Supply Type (Bottom Slot)
00 No supply (use when only one supply is required)
01 Low Voltage ac (85 to 132 Vac rms)
02 High Voltage ac (175 to 264 Vac rms)
03 High Voltage dc (88 to 140 Vdc)
04 Low Voltage dc (20 to 30 Vdc)
C: Agency Approval Option
00 None
01 CSA/NRTL/C
02 ATEX/CSA (Class 1, Zone 2)
Note: Agency Approval Option C 02 is only available if Power Supply Type (Top Slot) Option is A 01 or A 02 and if Power Supply Type (Bottom Slot) Option is B 00, B 01, or B 02.
Technical Parameters
Input: 18–32 V DC (nominal 24 V DC) via backplane for the Bently Nevada 3500/15-04-04-00
Outputs:
24 V DC @ up to 6 A total (fused per slot)
12 V DC @ up to 2 A auxiliary in the Bently Nevada 3500/15-04-04-00
Regulation: ± 5 % over full input and load range
Ripple & Noise: < 50 mV p-p on both rails
Protection:
Polyfuse (auto-reset) per output rail
Reverse-polarity input protection
Over-temperature shutdown with auto-recover within Bently Nevada 3500/15-04-04-00
Isolation:
Input-to-output: 2 kV DC
Between outputs: 500 V DC
Indicators: Front-panel LEDs for “24 V OK,” “12 V OK,” and “Fault”
Product function
DC Conditioning: Cleans and regulates raw rack-bus DC to stable 24 V and 12 V rails via Bently Nevada 3500/15-04-04-00.
Power Distribution: Routes fused DC to each module slot via backplane.
Health Monitoring: Continuously supervises rail voltages and reports faults through system interface.
Application Areas
Intrinsic-Safety Racks: Powering onboard barrier cards using Bently Nevada 3500/15-04-04-00 in Zone 2/Div 2 environments.
Standard Monitoring Assemblies: Supplying proximity/vibration modules in control panels.
Retrofit and OEM Systems: Consolidating DC sources into single rack-mounted solution.
Test & Calibration Benches: Providing both voltage rails with Bently Nevada 3500/15-04-04-00 for bench verification.
