Brand: Bently Nevada Description: Half-height power module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 6 Payment Term: T/T Shipping Port: Shenzhen Bently Nevada 3500/15-05-05-00 half-height power supply module provides regulated power for 3500 series monitoring systems.
|
Manufacture |
Bently Nevada |
|
Model Number |
3500/15-05-05-00 |
|
Ordering Number |
106M1079-01 106M1081-01 |
|
Catalog |
3500 SERIES |
|
Country Of Origin |
America |
|
HS CODE |
853630000 |
|
Dimension |
25*5*12CM |
|
Packing Dimension |
27*7*14CM |
|
Weight |
1.5kg |
Ordering Information
3500/15 -AA-BB-CC
3500/15 -05-05-00
3500/15: Power Supply Module
05 (Power Supply Type (Top Slot)): Universal AC Voltage (85 to 264 Vac rms)
05 (Power Supply Type (Bottom Slot))：Universal AC Voltage (85 to 264 Vac rms)
00 (Agency Approval)：None
Technical Parameters
Input voltage range: 85 to 264 VAC rms.
Input frequency: 47 to 63 Hz.
Mounting slot location: Top slot.
Output voltage: 24V DC.
Efficiency: 80%.
Product Features
Modular design: half-height compact structure, compatible with 19-inch EIA standard rack, supports hot swap.
Redundant power supply configuration: Bently Nevada 3500/15-05-05-00 supports dual power supply design to improve system reliability.
Industrial-grade protection: built-in overvoltage, overcurrent, and short-circuit protection functions to adapt to harsh environments.
Real-time status indication: Bently Nevada 3500/15-05-05-00 equipped with power status LED indicator for easy operation and maintenance monitoring.
Global applicability: Bently Nevada 3500/15-05-05-00 wide voltage input range (85-264 VAC), adaptable to power grid standards in different regions
