Brand: Bently Nevada Description: 136180-01 Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 11 Payment Term: T/T Shipping Port: Shenzhen Bently Nevada 3500/92-02-01-01 136180-01 Bridges the 3500 Series digital backplane bus to plant networks and host systems. Ideal where real-time machinery-health data—vibration, position, process variables, alarms—must be shared with DCS/SCADA, asset-management platforms, or remote HMIs via Modbus RTU/TCP, OPC UA, or EtherNet/IP, without disrupting protection-system determinism.
|
Manufacture |
Bently Nevada |
|
Model Number |
3500/92-02-01-01 |
|
Ordering Number |
136180-01 |
|
Catalog |
3500/92 |
|
Description |
Communication Gateway Module |
|
Country Of Origin |
USA |
|
HS CODE |
8471800000 |
|
Dimension |
24*2.4*24 (CM) |
|
Weight |
1.4 kg |
Ordering Information
3500/92 Communication Gateway
3500/92-AA-BB-CC
A: I/O Module Type
01 ModbusRS232/RS422 I/O Module
02 ModbusRS485 I/O Module
03 Ethernet/RS232 Modbus I/O Module
04 Ethernet/RS485 Modbus I/O Module
B: Memory Type
01 Low Memory
C: Agency Approval Option
00 None
01 CSA/NRTL/C
02 CSA/ATEX/IECEx
Technical Parameters
Backplane Interface: Dual 50-pin connectors for 3500 digital bus in/out in Bently Nevada 3500/92-02-01-01 136180-01
Ethernet Ports: 2 × 10/100Base-T RJ-45 (supports link-redundancy)
Serial Ports: 2 × RS-485 (Modbus RTU) on pluggable terminal block
Supported Protocols:
Bently Nevada 3500-bus tunneling
Modbus RTU/TCP
OPC UA
EtherNet/IP (implicit messaging)
Performance:
Ethernet: up to 100 Mbps throughput
Serial: up to 115200 baud per port
Bus latency: ≤ 5 ms end-to-end for Bently Nevada 136180-01
Memory/CPU: 64 MB SDRAM, 16 MB Flash for firmware and tag buffering
Power: 24 V DC via backplane (18–32 V DC), ≤ 0.5 A
Isolation: 1 kV galvanic isolation on serial and Ethernet ports
Environmental:
Operating Temp: 0 °C to +70 °C
Storage Temp: –40 °C to +85 °C
Humidity: up to 95 % RH, non-condensing
Product function
Protocol Conversion: Maps 3500-bus data frames via Bently Nevada 3500/92-02-01-01 136180-01 into industry-standard protocols.
Data Aggregation: Buffers alarms, trends, and diagnostics for bulk transfer.
Redundancy: Dual-Ethernet with automatic failover.
Configuration & Diagnostics: Embedded web-UI and CLI in Bently Nevada 3500/92-02-01-01 136180-01 for network settings and monitoring
Application Areas
DCS/SCADA Integration: Feeding real-time machinery-health data using Bently Nevada 3500/92-02-01-01 136180-01 into control systems.
Asset-Management Systems: Streaming vibration trends to historian platforms (OPC UA).
Remote Monitoring: Tunneling 3500 data over industrial WAN with Bently Nevada 136180-01.
Safety & Shutdown Logic: Routing critical alarms into SIS via Modbus.
Legacy Integration: Bridging older installations via Bently Nevada 3500/92-02-01-01 136180-01 into IIoT frameworks.
