Brand: Bently Nevada Description: VGA Display Monitor Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 4 Payment Term: T/T Shipping Port: Shenzhen Bently Nevada 3500/94M-06-00-00 VGA Display Monitor belongs to industrial-grade condition monitoring display equipment. Its core function is to present all kinds of monitoring data of 3500 system in real time and provide visualization support for equipment operation and maintenance.
|
Manufacture |
Bently Nevada |
|
Model Number |
3500 |
|
Ordering Number |
3500/94M-06-00-00 |
|
Catalog |
- |
|
Country Of Origin |
United States (US) |
|
HS CODE |
8528521100 |
|
Dimension |
42*34*6.8cm |
|
Weight |
8.5kg |
Product Features
Bently Nevada 3500/94M-06-00-00 can display the full amount of 3500 system information, including system event list, alarm event list, module/channel data, alarm and normal status, and supports 9 customized display modes (e.g., vibration measurement histogram, probe gap value, etc.).
Bently Nevada 3500/94M-06-00-00 can customize the screen layout through the 3500 Rack Configuration Software, which supports grouping display by unit, and data can be freely organized into customized pages.
The 15-inch LCD touch screen (LED backlight) is industrially hardened for harsh industrial environments and supports panel mounting with included mounting hardware.
Bently Nevada 3500/94M-06-00-00 connects directly to the 3500 rack (up to 6m/20ft) via standard cable without the need for an additional extender (due to BB=00).
Product Using Principle
Bently Nevada 3500/94M-06-00-00 acts as a display terminal for the 3500 Machine Protection System and works on the basis of the “Data Acquisition - Transmission - Visualization” process:
The 3500 system's sensors (e.g. vibration probes, displacement sensors) collect the equipment status data, which is processed by the 3500/22 TDI module (Transient Data Interface).
The 3500/94M module receives the processed data over a high-speed network and receives the touch control signals in conjunction with the RS232 interface.
The data is transmitted to the 15-inch touch screen through the VGA port and displayed in real time in the form of graphs (bar charts, lists, etc.), which supports the user to switch the page or configure the display content through touch operation.
Product Applications
Bently Nevada 3500/94M-06-00-00 is suitable for industrial scenarios that require real-time monitoring of the status of rotating machinery (e.g. turbines, compressors, pumps, etc.), and typical applications include:
Unit control rooms in power plants and chemical plants for centralized display of vibration, axial displacement, differential expansion and other parameters of key equipment.
Industrial field panel installation, convenient for operation and maintenance personnel in the vicinity of the equipment to quickly check the operating status and alarm information.
With the 3500 system to realize equipment failure warning and diagnosis, reduce unplanned downtime.
Product Parameter
The following are Bently Nevada 3500/94M-06-00-00VGA Display Monitor detailed parameter.
Display power supply: 24 Vdc (allowable range 12-24 Vdc), Inrush current 2.62 A @24V (<500µs), Operating current < 500 mA
3500/94M module power consumption: 4.6 watts max
Interfaces: VGA port (output analog RGB and sync signals), RS232 port (receive touch control data), front-end port (24Vdc power output, VGA signal output, touch command input)
Operating temperature: display 0-60°C (32-140°F), 3500/94M module - 20°C to 65°C (-22°F to 149°F)
Storage Temperature: 3500/94M Modules - 40°C to 85°C (-40°F to 185°F)
Humidity: display 95% RH (non-condensing), module 95% RH (non-condensing)
Protection rating: IP65 for the display (dust and low-pressure water spray)
Screen type: 15-inch LCD, LED backlight, resistive touchscreen
