Brand: Bently Nevada Description: AM3100T2-Z2 Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 14 Payment Term: T/T Shipping Port: Shenzhen Bently Nevada AM3100T2-Z2 is deployed in turbine-protection racks to combine vibration monitoring with trip logic based on shaft-speed inputs
|
Manufacture |
Bently Nevada |
|
Model Number |
AM3100T2-Z2 |
|
Ordering Number |
AM3100T2-Z2 |
|
Catalog |
IEPE Accelerometer Series |
|
Description |
ACCELEROMETER |
|
Country Of Origin |
USA |
|
HS CODE |
85389091 |
|
Dimension |
8*6*4 (CM) |
|
Weight |
0.06 kg |
Ordering InformationPart
|
Part Number |
Cable exit |
Sensitivity |
Accel range |
Frequency Range (3dB) |
Haz-area rating |
|
AM3100T2-Z2 |
Top exit sensor |
100 mV/g |
80 g |
0.4–14,000 Hz |
Zone 2 rated |
|
AM3100T2-Z2 |
Side exit sensor |
100 mV/g |
80 g |
0.5–10,000 Hz |
Zone 2 rated |
|
AP3500T2-Z1 |
Side exit sensor |
500 mV/g |
10 g |
0.2–2,300 Hz |
Zone 1 rated |
|
AP3500S2-Z1 |
Side exit sensor |
500 mV/g |
10 g |
0.2–3,700 Hz |
Zone 1 rated |
|
AM3100T2-Z0 |
Top exit sensor |
100 mV/g |
80 g |
0.4–14,000 Hz |
Zone 0 rated |
|
AS3100S2-Z0 |
Side exit sensor |
100 mV/g |
80 g |
0.7–10,000 Hz |
Zone 0 rated |
|
18IM6049 |
Top exit sensor |
100 mV/g |
60 g |
0.5–12,000 Hz |
Zone 0 rated |
Technical Parameters
Inputs:
2 × proximity-probe speed channels (0–50 Vp-p) for the Bently Nevada AM3100T2-Z2
2 × IEPE or ±10 V accelerometer channels (0.5 Hz–5 kHz)
Signal Conditioning:
Automatic probe-gain compensation
Bandpass filtering (field-selectable 1×, 2×, broadband vibration bands) in the Bently Nevada AM3100T2-Z2
Trip Logic:
Dual overspeed setpoints per speed channel
Vibration trip when amplitude exceeds set threshold
No-turn (stall) detection
Redundancy: Dual-channel processing with cross-monitoring and fail-safe voting
Outputs:
2 × Form C relays (overspeed) from the Bently Nevada AM3100T2-Z2
2 × Form C relays (vibration trip)
1 × Form C no-turn relay
Response Time: ≤ 2 ms from trip condition to relay actuation
Power: 24 V DC, ≤ 4 W
Environmental: 0 °C to +70 °C operating; up to 95 % RH non-condensing
Product function
Integrates high-speed vibration analysis with shaft-speed trip decisions through the Bently Nevada AM3100T2-Z2 in a single safety-hardened module. Continuously monitors probe and accelerometer signals, applies field-configured filters and thresholds, and issues deterministic trip outputs for immediate turbine shutdown.
Core Supporting Modules
AM31xx Rack Chassis: 3 U shelf providing power and backplane communications for Bently Nevada AM3100T2-Z2 protection modules
AM31xx Logic/CPU Module: Centralizes configuration and monitors module health
Relay Output Module: Collects trip signals and drives external shutdown contactors
Probes & Transducers: Eddy-current probes and accelerometers to the Bently Nevada AM3100T2-Z2 with shielded cabling
