Emerson KJ1501X1-BC2

Details

Overvier of Emerson KJ1501X1-BC2

Due to the most extensive output signals and functions, Emerson KJ1501X1-BC2 elaborately extends a comprehensive strategy towards the effective and accurate monitoring and control signals for the industrial control system.

Specification of Emerson KJ1501X1-BC2

Input voltage range

It generally supports a wide range of input voltage, typically ranging from 85VAC to 264VAC.

Input frequency

It has adaptation for input frequency of 50Hz/60Hz industrial frequency.

Sensor signal inputs

two independent sensor signal inputs, sens1h(z8)/sens1l(z10) and sens2h(d8)/sens2l(d10), with input voltage range 0...-27.3VDC.

TTL pulse outputs

there are two TTL pulse outputs; each pulse output shall live each output channel, while the output voltage shall be from 0 to +5V. The pulse width and frequency would be the same as the sensor signal; output can either take a rear-terminal (z14/z16) connection or be measured using the SMB interface on the front panel. Also, the width and frequency should be aligned with the sensors.

Key phase signals

there would actually be two key phase signal outputs, one each channel, which can go up to a voltage of 24V; the signal can be measured through the key phase slot, and one key output can help connect up to 15 mms6000 modules in parallel.

RPM current outputs:

there are two current outputs for RPM, 0/4...20mA, one for each channel, referred to as output terminals z18/b18, z20/b20. 6. Operating temperature range: usually able to operate well at ambient temperature - 10°C - 50°C.

Storage temperature range： - 20°C - 70°C.

Key Features of Emerson KJ1501X1-BC2

Relative humidity: refrigerate a very relative humidity range of 10% - 90% with no condensation.

The rich sources of output signals: Apart from the traditionally used sensor signal input, it has other output knots TTL pulse output, key signal output and other speed current output terminals, which supply full-spectrum and precise monitoring as well as control signals to the industrial control system and realize multi-dimensional monitoring and control of the machine operating status.

Stable working power supply: The two-channel 26.75 volts DC supply can be used to supply power to the sensor in order to secure stable sensor operation, thereby backing the accuracy and reliability of signal acquisition, which forms the basic guarantee for the stable operation of the entire system.

Multi-sensors: Its versatility permits a few ranges of sensor connections such as Germany epro pr6423 + con021 eddy current sensor or pr9376 Hall effect sensor, etc., to serve the necessities of different industrial measurements with signal acquisition scenarios.

Applications of Emerson KJ1501X1-BC2

Electric Power Industry

Emerson KJ1501X1-BC2 use is rife in DCS monitoring systems for the power plant, integrated automation control system for substations, enabling the monitoring and control of generator set operating states, transformer, and other equipment aimed at stabilizing the power grid.

Chemical Industry:

Emerson KJ1501X1-BC2 plays a prime role in simple computer control in the constant flow system for chemical liquids inside the factory and monitoring and control of temperature, pressure, volume flow rate, etc., during the chemical production process; facilitates an efficient automated production process in chemical industries.

Iron and steel industry

An intelligent flat steel furnace system for controlling and monitoring steel plant production equipment, real-time monitoring of operating parameters of the equipment, potential failures detected and corrected promptly so as to enhance production efficiency and product quality.

Mechanical manufacturing industry

The controlling module of the CNC machinery system and its signal processing provide the key to control machining processes and production automation, thus improving the efficiency of production and accuracy of processing.

Other fields

Emerson KJ1501X1-BC2 can be widely used in oil and gas, paper and printing, textile printing, dyeing and finishing, electronics manufacturing, automotive manufacturing, cigarettes, plastic machinery, water conservation, water treatment / environmental protection, municipal engineering, boiler heating, and many energy transmission and distribution, among other, fields in automation control system, providing robust support to controlling the industrial production process intelligently.
