Brand: ABB Description: Analog Output Module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 4 Payment Term: T/T Shipping Port: Shenzhen ABB AO810 can communicate with various controllers, receive digital signals from the controllers, and then convert the digital signals into corresponding analog voltage or current signals based on the set output range and resolution. These analog signals are used to control external actuators, such as valve opening, motor speed, or heater power, thereby achieving precise control of various physical quantities in industrial processes.
|
Manufacture |
ABB |
|
Model Number |
AO810 |
|
Ordering Number |
3BSE008522R1 |
|
Catalog |
800xA |
|
Country Of Origin |
Switzerland |
|
HS CODE |
8471800000 |
|
Dimension |
12*10*6cm |
|
Weight |
0.2kg |
Product Features
ABB AO810 offers a resolution of up to 14 or 16 bits, ensuring the accuracy of the output signal. It can precisely convert digital commands into analog signals, enabling precise control of the equipment.
ABB AO810 features 8 output channels, each of which can be independently configured to support different output ranges and signal types, enabling simultaneous control of multiple devices.
ABB AO810 supports voltage signal output, such as 0-10V, as well as current signal output, such as 4-20mA and 0-20mA. Users can flexibly switch between output types via software.
ABB AO810 features open-circuit detection for channels. When the output current is less than the set value and the set value exceeds 1mA, a channel error alarm is triggered. It also monitors process power supply voltage, when the supply voltage falls below the threshold, the module status indicator displays a fault. Additionally, the self-diagnostic function continuously monitors hardware status to ensure long-term stable operation.
ABB AO810 has Profibus DP or Ethernet communication interface that can be integrated into a variety of PLC and DCS systems, so that two devices can communicate data between multiple systems.
Product Application
ABB AO810 can be used for temperature and pressure control in chemical reactors, precisely adjusting the speed of the stirrer and the power of the heater to ensure the stability of the reaction process and product quality.
ABB AO810 can control the speed regulator of a steam turbine to ensure the stability of the grid frequency, and can also be used to monitor and control various parameters of power equipment, such as voltage, current, and power.
ABB AO810 is suitable for controlling the actuators in mechanical production machine, including tool feed movement and the movement of the workbench, to guarantee a high processing precision and production efficiency.
ABB AO810 can adjust the valve opening and fan speed of air conditioning units to achieve precise control of temperature and humidity, providing a comfortable indoor environment.
In oil and gas extraction, transportation, and processing, ABB AO810 can be used to control various valves, pumps, and compressors, ensuring the safety and efficiency of the production process.
Product Parameter
Here is ABB AO810 Analog Output Module detail.
Number of output channels: 8
Output signal types and ranges: Voltage signals are 0-10V, current signals are 4-20mA, 0-20mA
Resolution: 14-bit or 16-bit
Load capacity: For AO810, the maximum load resistance for current output is 500/750 ohms, for AO810V2, the load for current output is ≤500Ω (single power supply) and 250-850Ω (dual power supply)
Power supply voltage: DC 24V
Operating temperature range: -20℃ to 60℃ (AO810V2, no condensation), -20°C to +70°C (another statement for AO810V2)
Protection class: IP20
