Brand: ABB Description: Communication Interface Module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 7 Payment Term: T/T Shipping Port: Shenzhen ABB CI546 3BSE012545R1 is a communication module that combines status monitoring and execution control to build efficient and stable equipment interconnection and control networks for complex application scenarios such as power, chemical and manufacturing.
|
Manufacture |
ABB |
|
Model Number |
CI546 |
|
Ordering Number |
3BSE012545R1 |
|
Country Of Origin |
Switzerland |
|
HS CODE |
85389091 |
|
Dimension |
26*3*13cm |
|
Packing Dimension |
28*5*15cm |
|
Weight |
0.8kg |
Technical parameters
Type: VIP communication interface module
Power supply: 24V DC ±10%
Operating temperature: 0°C~60°C; -20°C~50°C
Storage temperature: -25°C~70°C
Protection level: IP20
Installation method: Rack-mounted/wall-mounted
Interface type: VIP bus interface
Communication rate: VIP bus standard rate
Remote interface: RS232/RS485
Input current: ≤4A
Output current: ≤8A
Analog input range: 0-10V, 4-20mA
Digital channel: Configurable I/O number
Diagnostic function: Real-time monitoring of communication status, support for fault location
Functional features
1. Industrial-grade communication core
As the communication hub of the ABB Advant OCS system, ABB CI546 3BSE012545R1 supports VIP bus protocol ensures real-time transmission of control instructions in high-risk scenarios such as oil and electricity, and redundant design eliminates the risk of single point failure
2. Flexible signal processing
Digital expansion: drive 8A high-power loads (such as solenoid valves, relays), compatible with switch devices
Analog acquisition: directly receive 0-10V/4-20mA industrial sensor signals (such as temperature and pressure transmitters)
3. Intelligent operation and maintenance support
ABB CI546 3BSE012545R1 built-in real-time diagnostic tools, remotely monitor bus status through RS232/RS485 interface, quickly locate communication interruption or signal abnormality
ABB CI546 3BSE012545R1 support modular maintenance, hot-swappable replacement, reduce system downtime
4. Wide environmental adaptability
Withstands a wide temperature range of -20°C~60°C and industrial vibration, suitable for harsh environments such as chemical plants and power stations
Application scenarios
1. Oil and gas
Oil and gas pipeline transmission control: Real-time monitoring of pipeline pressure, flow and valve status through the bus to ensure safe transportation
Offshore drilling platform equipment linkage: Ensure the coordinated operation of key equipment such as drilling pumps and separators in harsh environments
2. Power system
Thermal power plant DCS system: Coordinate boiler combustion control and turbine speed control instruction transmission
Substation automation: Monitor circuit breaker status and remotely trigger protection device action
