Brand: ABB Description: Engineering Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 8 Payment Term: T/T Shipping Port: Shenzhen ABB PU516A 3BSE032402R1 has become the core control unit in the field of industrial automation due to its high-precision triggering, optical isolation and anti-interference design, and flexible communication expansion capabilities.
|
Manufacture |
ABB |
|
Model Number |
PU516A |
|
Ordering Number |
3BSE032402R1 |
|
Catalog |
Advant OCS |
|
Country Of Origin |
Sweden |
|
HS CODE |
8538900000 |
|
Dimension |
30*13*5CM |
|
Packing Dimension |
32*15*8CM |
|
Weight |
0.8kg |
ABB PU516A 3BSE032402R1 Engineering Board’s modular installation and user-friendly operation interface can greatly improve production efficiency and system reliability, especially suitable for the laser semiconductor industry with strict requirements on stability and precision.
Technical Parameters
Communication interface: Support RS-232C standard interface, optional GPIB (Opt.01) or USB (Opt.11), printer port and Go/NoGo output.
External trigger: Trigger voltage range ±15V, trigger sensitivity is 50mV at DC-25MHz, 100mV at 25MHz-100MHz, input impedance 1MΩ±2%, maximum input range 300V (DC+AC peak).
Protection function: integrated overcurrent circuit breaker, regenerative overvoltage circuit breaker, undervoltage protection, instantaneous power failure protection and overload circuit breaker, etc.
Operating temperature: standard industrial temperature range (specific values need to refer to the manual, the webpage is not clear).
Anti-interference design: Adopt optical isolator technology to avoid signal reverse reflection, suitable for high-precision laser semiconductor industry
Function Principle
Human-computer interaction: through the touch screen operation interface (HMI), support parameter setting, real-time monitoring, alarm management and data input.
Automation control: integrated programmable logic controller (PLC) function to achieve precise control of industrial processes, such as laser equipment, automated production lines, etc.
Data management: ABB PU516A 3BSE032402R1 Engineering Board supports 15 sets of measurement condition storage and call, and 2 sets of waveform storage function, which is convenient for data backtracking and analysis.
Technical Principle
Signal processing: using optical isolator technology, input/output polarizer components to ensure that signal transmission has no reverse interference, suitable for laser applications with high stability requirements.
Dynamic adjustment: through the automatic setting function, the vertical system, horizontal system and trigger level are adjusted in real time to optimize the measurement and control accuracy.
Communication architecture: based on RS-232C or optional GPIB/USB interface, ABB PU516A 3BSE032402R1 Engineering Board realizes data interaction with PLC, sensors and remote monitoring systems, and supports Internet of Things (IoT) integration.
