ABB SPHSS13 hydraulic servo module

Technical Specifications

Symphony Plus is a platform-based system. Its technical specifications vary depending on the specific components (controller, I/O modules, etc.), but its core specifications reflect its high performance and robustness.

Controller Performance

• Processing Capacity: Covers applications from small to very large. For example:
• SPC600: Supports 5,000 function blocks and 500 I/O points.
• HPC800/SPC800: Supports up to 30,000 function blocks and 5,000 I/O points, with control loop execution times faster than 250 milliseconds.
• Processor and Memory: Utilizes an industrial-grade RISC processor with memory configurations ranging from 128MB RAM and higher, ensuring stable operation of complex logic.
• Program Cycle Time: Configurable down to 1 millisecond, meeting high-speed control requirements.

I/O Module Accuracy and Performance:

• Analog Input (AI): 16-bit resolution, with an accuracy of up to ±0.1% FSR (full-scale range).
• Analog Output (AO): 12-bit resolution.
• Digital I/O: Supports SOE (Sequence of Events) with a timestamp resolution of 1 millisecond for precise fault analysis.
• HART Support: Natively supports the HART protocol, allowing digital device information to be overlaid on analog signals.

Environmental Compatibility

• Operating Temperature: A wide operating temperature range, such as the SD series controller, supports -40°C to +70°C, making it suitable for harsh industrial environments.
• Protection and Certification: Complies with multiple international standards (such as IEC/EN 60068 and IEC 61000), and offers an ISA G3-level anti-corrosion coating option for use in highly corrosive environments.

Communication Network

• Control Network (PN800): 100 Mbps redundant Industrial Ethernet network with support for PRP (Parallel Redundancy Protocol) for zero-switching-time network redundancy.
• I/O Bus (HN800): 4 Mbps high-speed bus, extendable up to 3 km via fiber optic cable.
• Protocol Support: Natively integrated with PROFIBUS DP, Modbus TCP, IEC 61850 (GOOSE/MMS), IEC 60870-5-104, and DNP 3.0.

Application Scope

Symphony Plus's flexibility and scalability make it suitable for a wide range of industrial applications:

Energy and Power

• Conventional thermal power: Boiler, steam turbine, and auxiliary equipment network control.
• Renewable Energy: Photovoltaic power plants and wind farms (SCADA).
• Grid Management: Substation automation, integrated via IEC 61850.

Water and Wastewater Treatment

Plant-wide control and wide-area SCADA, from water intake and treatment to pipeline transmission and pumping stations.

Oil, Gas, and Chemicals

Upstream extraction, long-distance pipeline SCADA, and process control in refineries and chemical plants.

Industrial Manufacturing

Complex process control and production management in metallurgy, mining, cement, papermaking, food and beverage, and life sciences.
