Allen Bradley 1746-OB16

Output Voltage: 24V DC.

Operating Voltage Range: 10 - 50 VDC.

Backplane current: 5.1 Volts- 0.280 A.

Continuous current per module, Max: 6.4 A @ 0...60 °C (32...140 °F).

Off-state Leakage Current: 1 ma.

Output delay time, Off to On: 1.0 ms.

Output delay time, On to Off: 0.1 msStep Response- 60 milliseconds in, 2.5 milliseconds out.

Heat dissipation: 7.6 watts.

Shock resistance: 30 g operational shock.

Vibration resistance: 2.5 g operational vibration at 57 to 200 hertz.

Function Features

Precise Output Control: Allen Bradley 1746-OB16 allows for precise, fast output control, ensuring exact operation of the devices connected to it. The on-state voltage drop is 1.0 V at 1.0 A, and the fault current per point capacity is 4.0 A at 10 ms, enabling reliable power delivery to the connected devices.

Programmable Configuration: Allen Bradley 1746-OB16 allows for RSLogix 500 programming, giving the customer freedom to arrange the configuration according to specific switching needs for targeted industrial applications.

Diagnostic Capabilities: Incorporated within Allen Bradley 1746-OB16 is the ability to self-diagnose, facilitating speedy degradation, fault identification, troubleshooting, maintenance, and the avoidance of extended downtime.

Fault Diagnostics: This means it has built-in facilities to properly diagnose problems or other degrading conditions that may arise. This will enable timely fault detection, troubleshooting, and maintenance and minimize downtime.

Compatibility:  Allen Bradley 1746-OB16 easily integrates into the existing Control System, shortening installation time with a greatly simplified configuration process.

Applications

Machine Control Systems: Allen Bradley 1746-OB16 is prominently shaped into an industrial machine controller; CNC machines, injection molding machines, and packaging machines can all function to enable precise control of movement, sequencing, and operations.

Process Automation: In process industries such as chemical, pharmaceutical, and food and beverage, it's for controlling valves, pumps, conveyors, amongst other pieces of equipment to ensure smooth manufacturing processes and product integrity.

Robotics：Allen Bradley 1746-OB16 plays an important role by providing the output control signals that drive motors and actuators to provide precise and synchronized movements of robotic arms and end-effectors and hence increases performance and accuracy in robotic operations.

Material Handling: It is used for material handling systems like conveyor belts, cranes, and automated guided vehicles (AGVs), to control the movements and placements for materials, improving the handling efficiency and accuracy.

Packaging and Labeling: In packaging and labeling equipment, Allen Bradley 1746-OB16 controls functions like product feeding, packaging sealing, and label application to ensure accurate and efficient packaging operations.
