Allen Bradley 1746-OV16

Technical Parameter

Voltage Range: 10 - 50 volts DC .

Nominal Output Voltage: 24 volts DC .

Backplane Current (5 volts DC): 0.270 A .

Off-State Leakage Current: 1 mA .

Minimum Load Current: 1 mA .

Maximum On-State Voltage Drop: 1.2 V at 0.5 A .

Maximum resistive load on: 0.1 ms; off: 1.0 ms.

Heat Dissipation per Point: 0.388 W .

Total Heat Dissipation: 7.6 W .

Communication Circuits: 500 V DC .

Backplane: 1500 VAC .

Function Features

Isolated Outputs: The Allen Bradley 1746-OV16 has isolated output channels. Each output channel is electrically isolated from others, thus providing a better degree of safety from electrical disturbance and fault, and does not allow any problem in one channel to affect the whole system.

LED Indicators: Allen Bradley 1746-OV16 is fitted with LED indicators for all output channels. These indicators show a visual status display, thus facilitating understanding of the on/off state of each output, which is helpful in troubleshooting and maintenance.

Configurable Output Modes: Allen Bradley 1746-OV16 has modes of operation for both sinking and sourcing; this makes it very flexible for easy incorporation in every industrial control architecture so as to interface with different input devices and controllers.

Reliability: Allen Bradley is renowned for its manufacturing standard considerations, and it is built to withstand harsh industrial environments, with its robust construction and excellent thermal management. It has long-standing MTBF, thus guaranteeing an uninterrupted and highly reliable operation in process industries.

User-Friendly: Allen Bradley 1746-OV16 is relatively an easy product to install and operate. The standard form factor and clear pin assignment makes the wiring into control cabinets relatively easy. The guide LED indicators and easy programming interfaces help to augment the overall user-friendliness.

Applications

Manufacturing: In factories, it control various production equipment such as conveyor belts, motors, and pneumatic actuators. Allen Bradley 1746-OV16 can be integrated with automated assemblies, machine tool control systems, and packaging machinery, thus ensuring precise and efficient operations.

Automotive Industry: It is applied in the automobile manufacturing industries for controlling the robotic arms in the welding and assembly processes, functionality of hydraulic systems and pneumatic systems for vehicle component tests and production.

Food and Beverage Processing: It is used in controlling valves, pumps, and agitators along the lines of food and beverage processing. Allen Bradley 1746-OV16 assists with regulating flow in ingredients, temperature, and pressure, while allowing hygienic and efficient operations of processing equipment.

Material Handling: It controls conveyor systems, stacker cranes, and sorting equipment in warehouses and distribution centers. Allen Bradley 1746-OV16 provides smooth transfer and sorting of materials, Heuristic Functionality toward efficient and accurate transfer of materials.
