Brand: Allen Bradley Description: SERCOS Interface Module Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 4 Payment Term: T/T Shipping Port: Shenzhen Allen Bradley 1756-M08SE is specifically designed for multi-axis motion control in industrial automation, connecting ControlLogix controllers with servo drives via SERCOS III to achieve high-precision, real-time motion control, supporting up to 16 axes and 8 SERCOS interface drives.
|
Manufacture |
Allen Bradley |
|
Model Number |
1756-M08SE |
|
Ordering Number |
1756-M08SE |
|
Catalog |
ControlLogix |
|
Country Of Origin |
Switzerland |
|
HS CODE |
8473309000 |
|
Dimension |
14*14*10cm |
|
Weight |
0.6kg |
Product Features
Allen Bradley 1756-M08SE subscribes to SERCOS data rates of either 4 or 8 megabits per second, providing precise, low-latency communication for sending and receiving data between the controller and drive necessary to handle the most demanding, real-time motion control applications.
Allen Bradley 1756-M08SE allows fiber optics to be connected using TX (transmit) RX (receive) ports and supports plastic fiber (32m) and glass fiber (200m), highly resistant to electromagnetic interference, so it is used in harsh industrial environments.
Allen Bradley 1756-M08SE works with all SERCOS drivers such as the 2094 Kinetix 6000, 2098 Ultra 3000, 1394 SERCOS driver, 8720 MC axis, and more.
Allen Bradley 1756-M08SE is compatible with both single-turn and multi-turn absolute encoder feedback, which no longer causes the loss of position in case of power shutdown, and thus ensures a reliable system operation.
Allen Bradley 1756-M08SE is equipped with 4000V lightning protection, 1.5A overcurrent protection, 600W surge protection and an IP30 protection rating for dust and vertically falling drops of liquid.
Product Working Principle
Allen Bradley 1756-M08SE serves as a bridge between the ControlLogix controller and SERCOS drives, transmitting motion commands (such as position and speed) from the controller to the drives in real time via fiber optics, and providing feedback on drive status (such as current and faults).
It can be configured using RSLogix 5000 or Studio 5000 software, including creating motion groups, configuring axis parameters (such as units, positioning type), and writing ladder logic motion commands.
The SERCOS protocol uses periodic data frame transmission to ensure synchronization and precision in motion control, making it suitable for multi-axis collaborative operation scenarios.
Product Application
Allen Bradley 1756-M08SE can be used in industrial automation, material handling, and process control.
Industrial Automation:
Machine tool processing (e.g., CNC milling machines, lathes): Enables multi-axis coordination and high-precision positioning.
Robot control: Supports complex trajectory planning and real-time synchronization for robotic arms.
Packaging machinery: Coordinates multi-axis movements such as conveying, sorting, and packaging to enhance production efficiency.
Material Handling:
Semiconductor Manufacturing: Wafer handling and precise positioning.
Logistics and Warehousing: AGV (Automated Guided Vehicle) path control and sorting systems.
Process Control:
Printing and Textile Machinery: Tension control and synchronized drive.
Food and Beverage Production Lines: Continuous motion control for filling, labeling, and other processes.
