Bently Nevada 330106-05-30-05-02-05

Product Overview

Measurement Type: Vibration Velocity (RMS)

Measurement Range: 0-20 mm/s (±3% FS)

Frequency Response: 5-2000 Hz (±3 dB)

Output Signal: 4-20 mA DC (two-wire, ISA standard)

Accuracy: ±0.25% FS (at 25°C, factory calibrated)

Supply Voltage: 12-28 V DC (nominal 24V DC)

Operating Temperature: -40°C to +150°C (-40°F to +302°F)

Protection Rating: IP68 (NEMA 6P, submersible up to 1m)

Cable Entry: M12×1.5 threaded (stainless steel gland)

Mounting: 1/4"-28 UNF threaded stud (standard) or magnetic adapter (optional)

EMC Compliance: EN 61000-4-2/3/4/5/6/8/9 (immune to EMI/RFI/ESD)

Long-term Stability: ≤±0.05% FS/year (under stable conditions)

Shock Resistance: 100g peak (11ms, IEC 60068-2-27)

Calibration: Factory pre-calibrated (ISO 17025 traceable, includes calibration certificate)

Product Features

Bently Nevada 330106-05-30-05-02-05 with a frequency range of 5-2000Hz, it accurately captures the full-band vibration characteristics of rotating machinery, from low-speed bearing friction to high-speed rotor resonance. Its 0.25% full-scale accuracy enables detection of even the smallest vibration changes.

Bently Nevada 330106-05-30-05-02-05 used IP68 protection rating and 316L stainless steel housing enable direct installation in underwater equipment, high-temperature steam areas, or highly corrosive chemical environments.

Bently Nevada 330106-05-30-05-02-05 integrated triple shielding (conductor shield + double-layer braided mesh + integral metal housing) and digital filtering circuitry suppress electromagnetic interference generated by inverters, welding machines, and other equipment, achieving an output signal-to-noise ratio exceeding 90dB.

Applications

Bently Nevada 330106-05-30-05-02-05 widely used in key rotating equipment in the power, petroleum refining, metallurgy, and papermaking sectors, this sensor captures vibration amplitude and frequency characteristics to enable early fault diagnosis.

Compatibility with Other Models

For monitoring high-vibration equipment or long-distance transmission (over 1000 meters), the Bently Nevada 330106-05-30-05-02-05's 20 mm/s range and robust 4-20 mA signal are unmatched by other models.

Compared to the 330104-01-12-05-01-05 with the same protection level, its 20 mm/s range covers a wider range, enabling vibration monitoring of both low-speed and high-speed equipment, reducing spare parts requirements.

In environments with strong electromagnetic interference, the 05-30-05-02-05's 4-20 mA current signal offers superior interference immunity compared to voltage output models (such as the 330130-085-01-05).
