Brand: Bently Nevada Description: Ranger Pro Wireless Condition Monitoring Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 10 Payment Term: T/T Shipping Port: Shenzhen The Bently Nevada 190501-19-00-04 Velomitor CT Velocity Transducer Ranger Pro Wireless Condition Monitoring System, based on the standard Velomitor piezoelectric velocity sensor, is a low-frequency velocity sensor designed for accurately measuring the housing vibration velocity of equipment operating at 90 rpm and above, such as cooling towers and air-cooled heat exchanger fan assemblies.
|
Manufacture |
Bently Nevada |
|
Model Number |
70M303-10-01-01-01 |
|
Ordering Number |
70M303-10-01-01-01 |
|
Catalog |
- |
|
Country Of Origin |
America |
|
HS CODE |
8414909090 |
|
Dimension |
12*12*3CM |
|
Packing Dimension |
17*15*5CM |
|
Weight |
0.8kg |
Product Overview
Sensitivity: 3.94 mV/mm/s (100 mV/in/s), accuracy: ± 5%.
Frequency Range: Frequency response: 3.0 Hz to 900 Hz ± 1.0 dB, or 1.5 Hz to 1.0 kHz ± 3.0 dB.
Operating Temperature Range: -40°C to +85°C.
Storage Temperature Range: -40°C to +100°C.
Feature
Bently Nevada 190501-19-00-04 with unique low-frequency design precisely adapts to vibration monitoring of low-speed equipment, such as cooling towers and air-cooled heat exchanger fan assemblies.
Bently Nevada 190501-19-00-04 with a sensitivity of 3.94 mV/mm/s (100 mV/in/s) ± 5%, it accurately measures minute vibration velocity changes and promptly detects abnormal vibrations during equipment operation.
Bently Nevada 190501-19-00-04 has a frequency response range of 3.0 Hz to 900 Hz ± 1.0 dB or 1.5 Hz to 1.0 kHz ± 3.0 dB covers a wide range of vibration frequencies generated during equipment operation.
Bently Nevada 190501-19-00-04 used 316L stainless steel housing ensures long-term stable operation in harsh industrial environments, such as those exposed to high humidity, strong acids and alkalis, and high levels of dust.
Application
Bently Nevada 190501-19-00-04 used for vibration monitoring of cooling tower fans in power plants, this system monitors the fan's vibration speed in real time, enabling timely detection of wear and looseness of fan blades, as well as potential motor and reducer failures.
Bently Nevada 190501-19-00-04 installed on air-cooled heat exchanger fans in petrochemical plants, it effectively monitors fan operating status.
Compatibility and Integration
Software Support:
System 1 Software: Requires version 20.2 or higher, with Generic Client Interface (GCI) data output. Each sensor requires a separate System 1 device license (Part Number 3071/13).
Third-Party Tools: Supports Modbus data output for integrated data, facilitating integration into SCADA or PLC systems.
Gateway Compatibility:
ISA100 Gateways: Such as the Bently Nevada 70M320 (supports up to 50 sensors), Yokogawa YFGW410 (up to 160 sensors), or Honeywell WDM (up to 320 sensors).
Network Topology: Supports star or mesh networks, with a maximum depth of three hops, ensuring reliable data transmission.
