ICS Triplex T9402

Operational Parameters

Processor: The processor is equipped with a powerful processor with high data processing speed and efficient operation. The processing speed is fast and the response is quick, and it is often very fast when handling complex tasks.

Memory Capacity: ICS Triplex T9402 has a huge memory capacity, so large codes can be stored together with configuration data and historical process data. Adequate memory enables better application performance while adapting to different operating scenarios.

I/O Capacity: A large number of input and output channels are provided. The analog input channel has a wide operating voltage and current range (typically -10V to +10V and 4 - 20mA, respectively). The digital input channel accepts TTL or relay contact closure signals. The analog and digital output channels can drive a large number of actuators and devices. Examples include on/off operations using relays and similar binary devices, while the analog output channels drive various solenoids or motors.

Temperature and Humidity Range: The ICS Triplex T9402 has an operating temperature range of -20°C to +60°C. This makes it suitable for use in industrial environments with varying indoor and outdoor temperatures.

Power Requirements: The power supply voltage is typically 100V to 240V AC with an input frequency of 50/60Hz. The product has a built-in power redundancy option for continued operation during power failures or fluctuations.

Product Features

Redundant and Fault-Tolerant Design: The ICS Triplex T9402 incorporates a redundant architecture to provide high reliability. If a single component fails, the redundant component automatically takes over without interruption of service. This means that the availability of a fault-tolerant product reduces downtime for the entire system, thereby increasing the availability of industrial processes.

Control and Monitoring: Advanced control features in this product include PID control, feedforward control, and model predictive control. The control algorithm provides tight control of process variables (temperature, pressure, flow, and level). At the same time, the system also monitors process parameters and equipment status. In this process monitoring, abnormal conditions such as sensor failure, actuator failure, or process deviation are detected, and alarms are generated or corrective actions are taken.

Communication capabilities: ICS Triplex T9402 supports multiple communication protocols such as Ethernet, Modbus and Profibus, so it can be easily integrated with other devices and systems in industrial networks. It can communicate with sensors, actuators, HMI (Human Machine Interface) and higher-level control systems such as DCS (Distributed Control System) and SCADA (Supervisory Control and Data Acquisition) systems. This allows data and command exchange, enabling centralized control and monitoring of all industrial processes.

Programmability: ICS Triplex T9402 is a highly programmable device. It allows users to design custom control strategies and application-specific logic. It allows the use of programming languages such as ladder logic, function block diagram and structured text. This flexibility gives engineers the freedom to adapt the system to the specific needs of different industrial processes - chemical plants, power generation or oil and refining.

Application range

Oil and gas industry: ICS Triplex T9402 is used in wellhead control, pipeline monitoring and control, and gas processing in the oil and gas industry. It ensures safe and efficient operation of oil and gas production facilities by precisely controlling fluid flow, observing pressure and temperature conditions, and detecting any leaks or abnormal events.

Chemical Processing: Some of the applications in chemical plants are reactor control, distillation column control, and chemical metering. By regulating temperature, pressure, and chemical addition with high precision, it maintains the desired chemical reactions, controls product quality, and ensures the safety of chemical processes.

Power Generation: In power plants, the ICS Triplex T9402 is used to control turbines, boilers, and synchronize with the grid. By controlling the speed and output of turbines, maintaining steam pressure and temperature in boilers, and ensuring the stability of grid connections, it generates and distributes electricity efficiently.

Pharmaceutical Industry: The ICS Triplex T9402 is used in the pharmaceutical industry for process control of drug synthesis, purification, and packaging. By controlling temperature, pressure, and flow throughout the manufacturing process while monitoring the integrity of production equipment, finished products that meet the most stringent quality and safety standards can be obtained.
