Triconex 3510

Details

Performance Features

The Triconex 3510 belongs to the Triple Modular Redundant (TMR) microprocessor hardware category, and it always has three channels. Each channel can process different programs in parallel and independently, and obtain input/output (I/O) signals from the same physical units. The actual values of the I/O signals are obtained through a hardware voting procedure, while the analog signals are processed in the following way: the median value that appears most frequently is taken. The above structure ensures that any single point of failure will not adversely affect the operation of the system, thus enhancing the two advantages of system reliability and fault tolerance.

True Processing Power

The processing is carried out in real time, at a very fast speed, applying complex control logic. All of these are handled by a high-performance processor that can respond to multiple input and output signals simultaneously. By solving the complex tasks that frequently occur in industries such as chemical and power, it well meets the real-time control needs of multiple industrial scenarios.

Complete Input and Output Interfaces

It supports up to 118 I/O cards and offers a variety of communication cards for selection, enabling flexible configuration of various functions, including digital input/output, analog input/output, pulse input, etc., which is sufficient to meet the connection requirements of different types of industrial equipment and sensors.

Online Hot Swap Function

It supports the online insertion or removal and replacement of faulty cards without shutting down the system. This design greatly reduces the downtime for equipment maintenance and the risk of production interruption, while also improving the availability and maintainability of the system.

Remote Expansion Capability

The Triconex 3510 supports remote racks that are 12 kilometers apart, thus providing a convenient way for users to conduct centralized control and management of distributed equipment in large industrial sites. Meanwhile, it can also minimize the wiring costs and system complexity to the greatest extent.

Compliance with Stringent Safety Standards

Full compliance with the IEC61508/61511 standards endows the system with a high-level safety integrity rating, making it applicable to industries with high safety standard requirements, such as safety interlock systems, steam turbine control, gas turbine control, compressor anti-surge control, offshore oil platforms, fire and gas monitoring and protection in industries like petrochemical, oil refining, oil and natural gas, chemical, power, rail transit, aerospace, and nuclear industries.

Dedicated Software Development, Debugging, and Configuration Package

This package includes Tristation1131 software, which can provide users with a user-friendly and efficient programming, debugging, and configuration environment. It minimizes the knowledge threshold required for system development and maintenance, thereby improving work efficiency.

Intelligent I/O Cards

Each I/O card of the Triconex 3510 is equipped with a microprocessor. The microprocessor can screen input signals and diagnose hardware faults of the card. The microprocessor in the output card can provide voting information, check feedback data, and diagnose field line faults, significantly improving the system's fault diagnosis ability and reliability.

The Triconex 3510 is widely used in industrial transmission fields, including metallurgy, mining, papermaking, chemical, building materials, machinery, power, and construction systems. It can start and control any type of heavy-duty load motor, and simultaneously conduct precise control and protection for various equipment in the industrial production process.

IV. Maintenance and Management

1.Intuitive Alarm Indication: The main rack power module of the Triconex 3510 has a well-configured alarm indication function. When there is a configuration mismatch, module failure, or power failure within the system, the alarm contacts will be triggered to alert the maintenance personnel.

2.Online Diagnosis Function: It supports online diagnosis, facilitating real-time monitoring of the operating status of each module and channel in the system. This helps to quickly isolate fault points, enabling technical personnel to take effective remedial measures in a timely manner and further reducing the malfunction time of the equipment.

3.Fault Data Storage: It can record any fault and related data into the Non-Volatile Random Access Memory (NVRAM), which simplifies the management analysis and traceability process and provides data support for system optimization and improvement.

V. Environmental Adaptability

The Triconex 3510 can operate in harsh environments, possessing good anti-interference ability and stability, and can run reliably for a long time under severe industrial field environments.
