Allen Bradley 1756-M13

Technical Parameter

User Memory: 2 MB.

Digital I/Os: 128,000.

Analog I/Os: 4,000.

Vibration: 10-Hz to 500-Hz.

Communication Port: Allen Bradley 1756-M13 features an integrated RS-232 serial communication port.

Supported Protocols: DF1 full/half duplex, ASCII, DF1 radio modem, Modbus via logic, and DH-485.

Operating Temp: 0 to 60 degrees Celsius.

Storage Temp: -40 to 85 degrees Celsius.

Relative Humidity: 5% to 95%.

Backplane current at 5V DC：1.2 A.

Backplane current at 24V DC：14 mA.

Function Features

Ability for Expansion: Allen Bradley 1756-M13 greatly increases the memory capacity of the Controllogix 5555 controllers and therefore allows handling of larger and complex data and programs.

Automatic Recognition: Once inserted into the controller memory expansion slot, Allen Bradley 1756-M13 is automatically detected by the controller, eliminating manual operations for its configuration and further ensuring easy integration of the two devices into a unified control system.

Enhanced Performance: It enhances the performance of the Controllogix 5555 controllers by providing additional memory for enabling faster data processing and effective program execution.

Status Indication: The OK status indicator on the front panel of Allen Bradley 1756-M13 makes it easy for operators and technicians to verify that the memory module is properly installed, thus easing the installation and maintenance task.

Increased Memory Capacity: A big boost lies in that an additional 1.5 Mbyte memory offered by it would enable it to accommodate larger and complex applications with more flexibility in programming and data management.

Applications

Industrial Control: It is widely applied in assembly lines, material handling systems, and machine tool control processes. Allen Bradley 1756-M13 offers accurate control and feedback on other various production equipment, hence increasing production efficiency, product quality, and reliability within processes.

Building Automation: It finds use in HVAC designs, lighting control, and energy management applications in buildings. Allen Bradley 1756-M13 optimizes energy use, improves indoor environmental quality, and enhances overall efficiency of building operations.

Infrastructure Control: Allen Bradley 1756-M13 is usually seen in water-wastewater treatment plants involving the control of valves, pumps, and other equipment for treating and distributing water resources efficiently. It is also applied in power generation facilities to monitor and control generators, turbines, and other power-generating equipment for stable power supply.

Control in Process Industries: Allen Bradley 1756-M13 is at work in the chemical, pharmaceutical, and food and beverage industries for regulating and monitoring critical processes such as mixing, reaction, and packaging.
