ABA160 830-160-000-11X-A2-B104-C104

Material : Polyester reinforced with fibre-glass

Sealing : Silicone gasket

Finish : Black colour, surface resistance < 109 Ω

Exi certificate : PTB Ex-81/3102

Mounting : M4 x 20 Allen head screws

Protection class : IP 65, according to IEC classification

Temperature range: -40 to +100°C

Chemical : Good resistance to sea water, acids, alkaline solutions, solvents, gasoline and oils

Flammability : Self-extinguishing, halogen free

Stuffing glands : Reinforced polyamid or nickel-plated brass

Seals : Perbunan N

Key Features

ABA160 830-160-000-11X-A2-B104-C104 Ideal Fusion of Strong Engineering and Smart Design for Easy Installation

Added Security: With a screw-fastened polyester lid and silicone gaskets the enclosure conveniently separates the interior electronics from moisture, dirt and the elements to preserve its long-term stability. Flexible cable management with PG-7 to PG-11 stuffing glands, to 12mm cable diameter, is possible thanks to its modular design.

Compliance & Certification: With compliance to ATEX & IECEx standards, the ABA160 830-160-000-11X-A2-B104-C104 is Safety in Hazardous for the most stringent ATEX Zone 0/20 applications. Pre-drilled mounting holes allow for easy installation onto equipment or control panels.

Scalable: Whether using a single or multiple IPC704 conditioners, this enclosure is expandable to accommodate a large monitoring network in an industrial installation.

Application Scenarios

The ABA160 830-160-000-11X-A2-B104-C104 delivers reliable performance across industries:

Gas Turbine Health Monitoring: In a recent offshore platform project, the ABA160 830-160-000-11X-A2-B104-C104 housed IPC704 conditioners connected to CA134 accelerometers. This setup enabled continuous vibration tracking on GE Frame 9E turbines, reducing unplanned downtime by 25% through predictive maintenance alerts.

Hydroelectric Generator Air Gap Monitoring: Installed in a hydroelectric plant, the enclosure protected LS air gap sensors from humidity and debris, ensuring accurate rotor-stator gap measurements and extending sensor lifespan by 40%.

Automotive Manufacturing: A European car manufacturer used the ABA160 830-160-000-11X-A2-B104-C104 to shield vibration diagnostics tools during engine testing, achieving ISO 17025-compliant calibration for noise reduction analysis.
