Brand: AMAT Description:Interface Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty:5 Payment Term: T/T Shipping Port: Shenzhen As an interface board, AMAT 0100-20004 can realize data interaction and real-time monitoring among multiple modules, taking into account both process stability and system integration efficiency.
|
Manufacture |
AMAT |
|
Model Number |
0100-20004 |
|
Country Of Origin |
USA |
|
HS CODE |
85049020 |
|
Dimension |
20*12*2cm |
|
Packing Dimension |
20*14*4cm |
|
Weight |
0.7kg |
Input voltage: 100–240V AC
Output voltage: 24V DC
Communication interface: Ethernet (10/100Base-T), RS-485 (baud rate 9600–115200bps)
Operating temperature: -10℃ to 60℃
Data sampling rate: 100 Hz
Protection level: IP20
Installation method: Guide rail or screw fixation
Input range: -10V to +10V
Digital channel: 16 isolated input/output (support TTL/CMOS level)
Protocol support: Modbus TCP, DNET
Functional features
1. Multi-system signal routing hub
AMAT 0100-20004, as the core interconnection board, integrates high-density signal routing function to achieve seamless data interaction between chamber controller, sensor and main control unit, reduce wiring complexity and improve response speed
2. Anti-interference and stability guarantee
Triple electromagnetic shielding tec7hnology and isolated power supply design are used to ensure that AMAT 0100-20004 operates stably in a high-voltage radio frequency (RF) environment, and the signal error rate is less than 0.001%
3. Real-time process monitoring and diagnosis
0100-20004 built-in real-time data acquisition engine supports dynamic monitoring and abnormal alarm of process parameters (temperature, pressure, flow), helping AMAT 0100-20004 to achieve predictive maintenance and reduce the risk of equipment downtime
4. Rapid integration and compatibility optimization
Provide standardized interfaces and plug-and-play configuration, compatible with AMAT Centura 5200, Endura 5500 and other platforms, shortening the equipment debugging cycle by more than 30%
Application scenarios
1. Ion implantation process
Used for chamber signal integration of VIISta 3000XP/900XP ion implanters to achieve angle control and dose calibration
2. Thin film deposition equipment
Route gas flow, RF power and temperature signals in Centura CVD/PVD system to ensure film uniformity
3. Vacuum system control
Connect vacuum gauge, molecular pump and cooling unit to monitor vacuum degree and leak alarm in real time (such as Endura platform)
4. Wafer transfer automation
Drive robotic arms (such as Fetch Arm) and wafer positioning systems to improve transmission accuracy and throughput efficiency
