EA902 913-902-000-011-A1-E9500-F2-G9300

Brand: Vibro-Meter
Description:Extension cable
Condition: Brand New
Certificate: COO TEST REPORT WARRANTY LETTER
Warranty: 1 year
Inventory Qty: 6
Payment Term: T/T
Shipping Port: ShenZhen
The EA902 913-902-000-011-A1-E9500-F2-G9300 is an extension cable that transmits weak sensor signals with fidelity, ensuring that the entire measurement chain provides accurate shaft vibration or position measurement data over distances of up to 9.5 meters.

Send Inquiry

Product Description

Manufacture	Vibro-Meter
Model Number	EA902
Ordering Number	913-902-000-011-A1-E9500-F2-G9300
Country Of Origin	Switzerland
HS CODE	90318090
Dimension	Ø18 mm × 35 mm (sensor head) Electronic module: 45 mm × 32 mm × 25 mm
Packing Dimension	180 mm × 120 mm × 80 mm
Weight	0.4 kg

Detailed introduction

EA902 913-902-000-011-A1-E9500-F2-G9300 is a key component of the TQ9xx series eddy current displacement measurement chain of the Vibro-meter brand of Parker Meggitt - a high-performance extension cable. Designed for harsh industrial environments, the EA902 913-902-000-011-A1-E9500-F2-G9300 cable has A1 option certification and meets stringent explosion-proof requirements (Ex ec IIC T6 Gc). It is suitable for Zone 2 areas with potentially explosive gases. Its built-in F2 specification FEP jacket provides excellent chemical corrosion resistance, high temperature resistance (-40°C to 200°C) and mechanical protection (IP68 level), ensuring the long-term stable operation and signal integrity of the EA902 913-902-000-011-A1-E9500-F2-G9300 in key applications such as energy, petrochemicals and heavy machinery.

Core parameters and features advantages:

Core functions:

Serves as a signal transmission bridge between TQ902/TQ912 eddy current sensors and IQS900 signal conditioners, forming a complete eddy current displacement measurement chain.

Signal fidelity:

The 70Ω coaxial structure design ensures low loss and high fidelity of high-frequency sensor signals during transmission.

Critical length:

9.5 meters in length (E9500) for flexible combination into a measurement chain with a total system length (TSL) of 5 meters or 10 meters (for example: 5m TSL with 0.5m sensor cable, or 10m TSL with 0.5m sensor cable).

Reliable connection:

F2 specification self-locking micro coaxial connector ensures firm connection and signal stability with sensors and signal conditioners.

System compatibility: Designed specifically for TQ9xx sensors and IQS900 signal conditioners, components are interchangeable, making system construction and maintenance easier.

Application scenarios: Especially suitable for shaft vibration, axial displacement, speed measurement, and functional safety (SIL 2) applications of rotating machinery (such as turbines, compressors, pumps) that require explosion-proof certification.
