GE 151X1207BA10SA01 IC752SPL013

151X1207BA10SA01 is the signal transfer backplane for the GE EX2100 excitation system. It is used as a complete set in conjunction with the IC752SPL013 human-machine operation panel for local monitoring of the excitation cabinet of the synchronous generator in power plants. The panel is responsible for voltage and excitation current monitoring, local magnetic lifting and lowering operations, and fault viewing. The backplane provides 24V power supply, signal isolation and connection with the cabinet bus. The entire machine is powered by 24VDC, with a wide temperature range and the ability to withstand harsh industrial environments. It communicates with the excitation main control via optical fiber/serial port. It is mostly used for excitation regulation of gas turbine and steam turbine generators. A failure of the backplate can cause the panel to lose contact, and spare parts need to be replaced as a complete set.

Product Features

GE IC752SPL013 can monitor and control the excitation system of the generator to ensure that the voltage and frequency output from the generator are within the required range through real-time data exchange and communication to realize the stable operation of the power system.

GE IC752SPL013 has a variety of communication interfaces, such as Ethernet, Profinet IO, etc., in order to carry out efficient data exchange and communication with the excitation control system and other related equipment, making real-time monitoring and control more convenient and reliable.

GE IC752SPL013 is equipped with an automatic adjustment function, which can automatically adjust the parameters of the excitation system according to the actual operating conditions to maintain stable power output, which can greatly improve the operating efficiency and stability of the power system.

GE IC752SPL013 supports the TPM (Trusted Platform Module) 2.0 standard, which provides higher security and reliability, and is able to realize a secure environment on the microprocessor for operations such as encryption, decryption, signing, and storage of digital certificates, which effectively protects the data security of the power system.

GE IC752SPL013 also has digital I/O interfaces, which enables it to communicate with other digital devices. Through these interfaces, data and control signals can be transmitted to realize collaborative work with other devices, further improving the integration and operational efficiency of the power system.

As an Excitation Control Interface Module device with excellent performance and stability, GE IC752SPL013 is able to operate stably in a variety of complex and harsh industrial environments, ensuring the safe and reliable operation of the power system.

Product Parameter

GE IC752SPL013 specification data as below.

Processor: 32-bit RISC processor

Memory: 256 KB RAM and 512 KB Flash memory

Display: 7-inch color touch screen with a resolution of 800×480 or 320×240 pixels

Operating Voltage: Mainly 24 VDC, but some data indicate 220V; please confirm according to the actual model

Power Consumption: 20W

Operating Temperature Range: -20°C to 60°C or -40°C to +85°C; different data vary

Storage Temperature Range: -40°C to +85°C

Operating Humidity: 5% to 95% non-condensing
