Brand: GE Description: Terminal Digital Connector Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 10 Payment Term: T/T Shipping Port: ShenZhen Energy efficiency of GE DS200DTBBG1ABB ensures minimal power consumption while maintaining optimal performance, which is essential component in turbine control systems.
|
Manufacture |
GE |
|
Model Number |
DS200DTBBG1ABB |
|
Ordering Number |
DS200DTBBG1ABB |
|
Catalog |
Mark V |
|
Country Of Origin |
USA |
|
HS CODE |
8479909090 |
|
Dimension |
30cm*10cm*6cm |
|
Packing Dimension |
32cm*12cm*8cm |
|
Weight |
1.2kg |
Technical Parameter
Input voltage range: 24V DC to 125V DC.
Operating temperature range: - 30°C to 65°C.
Storage temperature range: -40°C to 85°C .
Terminal blocks: 2, each terminal block can accommodate up to 95 signal lines, which can effectively manage the lines.
Connectors: There are three 50-pin connectors for easy connection with other system components, and they are also equipped with bayonet connectors and jumpers.
Functional Characteristics
Digital Signal Termination: GE DS200DTBBG1ABB serves as the termination for digital contact inputs 47-96, providing dedicated connection points for specific digital input signals, ensuring accurate and reliable transmission of digital signals between field devices and the control system.
DIN Rail Mounting: GE DS200DTBBG1ABB is designed for DIN rail connection, allowing for convenient installation and removal. It can be vertically stacked on the DIN rail to save cabinet space, and if necessary, two DSVO boards can be linked to the VSVO.
Versatile Connection: The dual terminal blocks and multiple connectors of GE DS200DTBBG1ABB offer efficient wire management and flexible connection options, enabling seamless integration with other system components such as sensors, actuators, and controllers.
Board Configuration: On the DSVOH1B, the servo valve coil resistance ranging from 22W to 1,000W and the required coil current can be selected through jumpers JP1 and JP2.
Troubleshooting
Signal Transmission Failures：When signal transmission issues with GE DS200DTBBG1ABB arise, users should analyze the pulse axles. Make sure the signal cables are connected appropriately and not damaged. Measure and test signal level at the input and output ports with a multi-meter or oscilloscope if the signal is normal range. In case of normality of the signal, check the corresponding devices and circuits connected into the interface.
Board Issues: If the board itself has issues, inspect it for signs of damage (burnt components, loose connectors, broken traces, etc.) Whenever you can, utilize diagnostic tools or software to carry out a thorough check of the board's functions and status. Replace the board with a new one if it is faulty.
Application Areas
Turbine and Generator Control:GE DS200DTBBG1ABB plays an important role in the GE Speedtronic Mark VI control system to ensure the efficient signal connection between components in the turbine and generator control process.
Industry Automation: In a variety of industrial automation systems, it is used to connect sensors, actuators, and other control devices, to achieve real-time data acquisition, signal processing and device control, to improve the level of automation and production efficiency of the production line.
Power Plants: GE DS200DTBBG1ABB can be used extensively in the control system of a power plant to monitor and control the operation of various equipment such as boilers, turbines, and generators, ensuring the stable operation of the power generation equipment and the efficient conversion of energy.
