Brand: GE Description: Power Connect Card Condition: Brand New Certificate：COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 10 Payment Term: T/T Shipping Port: Xiamen GE DS200PCCAG6ACB is ideal for power generation plants and other industrial applications that demand precision, durability, and operational reliability. It is a top choice for industries requiring stable power distribution in challenging environments.
|
Manufacture |
GE |
|
Model Number |
DS200PCCAG6ACB |
|
Ordering Number |
DS200PCCAG6ACB |
|
Catalog |
Mark V |
|
Country Of Origin |
USA |
|
HS CODE |
85389091 |
|
Dimension |
30cm x 20cm x 4cm |
|
Packing Dimension |
33cm x 22cm x 7cm |
|
Weight |
0.8kg |
Product Overview
The DS200PCCAG1ADB is a power connection card in the PCCA (Power Connection Card) series produced by General Electric Industrial Control Systems, and it belongs to the DS200PCCA series. This card is mainly applied in DC drive systems, serving as an interface between the control circuit and the thyristor (SCR) power bridge, providing gate drive pulse signals and featuring voltage feedback and buffering circuit functions.
Function Feature
The gate drive interface of DS200PCCAG1ADB provides forward and reverse gate drive signals to the thyristor bridge through a pulse transformer.
Supports armature voltage feedback and regulation functions, suitable for different system voltage configurations.
Equipped with an AC/DC buffer circuit (suitable for medium and small power systems), it effectively suppresses voltage spikes.
The jumpers are configured through JP1, JP2, WP3 and WP4 to adjust and adapt to different system voltages and feedback connection methods.
Replacement Procedure
Matters needing attention during replacement.
First, cut off the power supply and confirm that the capacitor has been completely discharged.
Then open the front and rear circuit board brackets in sequence.
Disconnect all connection wires and loosen the circuit board fixing clips.
Finally, install the new circuit board and make sure that the jumper Settings are consistent with the original circuit board.
Application Areas
The GE DS200PCCAG6ACB is widely used in oil refineries and natural gas processing plants to manage complex processes in crude oil refining and natural gas processing. Users can track and monitor fluid flow, adjust pipeline pressure, and supervise the operating status of pumps and valves.
In scenarios where precise control of production processes (such as chemical mixing, equipment sterilization, etc.) is required during the production process in pharmaceutical factories and strict compliance with drug safety standards is necessary, this module can be used to control such process flows and environmental conditions such as clean rooms.
The DS200PCCAG6ACB is used to control mineral extraction and mining operation processes. The Power Connect Card can not only regulate the working status of mining equipment such as crushers, conveyors and ore separators, but also monitor safety-related parameters such as air quality and equipment vibration.
