Brand: GE Description: Signal Conditioner card Condition: Brand New Certificate：COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 10 Payment Term: T/T Shipping Port: Xiamen GE DS200PTCTG1BAA is a professional Potential Transformer Current Transformer (PTCT) signal processing module. As a key component of the GE Mark VI control system, it is responsible for isolating, collecting, and converting voltage and current signals in industrial sites.
|
Manufacture |
GE |
|
Model Number |
DS200PTCTG1BAA |
|
Ordering Number |
DS200PTCTG1BAA |
|
Catalog |
Mark V |
|
Country Of Origin |
USA |
|
HS CODE |
85389091 |
|
Dimension |
23cm x 19cm x 4.5cm |
|
Packing Dimension |
25cm x 22cm x 7cm |
|
Weight |
0.7kg |
Product Overview
The DS200PTCTG1BAA is a professional signal processing module for voltage transformers and current transformers (PTCT). As the core component of the GE Mark VI control system, the DS200PTCTG1B is responsible for isolating, collecting and converting voltage and current signals in the industrial field. This module is like the "sensory nerve" of the control system, ensuring the precise perception and safe transmission of power grid parameters.
Core Functions and Values
High-precision signal acquisition and isolation
Specialized in processing raw signals from voltage transformers (PT) and current transformers (CT)
The Signal Conditioner card provides comprehensive electrical isolation protection, effectively preventing on-site interference and high-voltage surges from damaging the core control system
Ensure the accuracy and stability of signal acquisition to provide a reliable data basis for system control decisions
Signal type compatibility processing
Supports auxiliary input/output of 4-20mA current signals and ±10V DC voltage signals
The flexible interface design meets the connection requirements of various sensors and actuators
Simplify system integration and reduce the complexity of peripheral circuit design.
Reliable system integration
The JKK flat cable connector enables seamless data exchange with the TCCB board.
The modular design of DS200PTCTG1BAA facilitates installation and maintenance, significantly reducing on-site wiring workload.
Industrial-grade components ensure long-term stable operation in harsh environments.
Technical Specifications
|
Parameter |
Specifications |
|
Product Model |
DS200PTCTG1BAA |
|
Board Type |
PTCT (Potential Transformer Current Transformer) signal processing board |
|
Main functions |
Voltage/current signal isolation, scaling and conversion |
|
Signal input |
PT/CT secondary side signal |
|
Auxiliary interface |
4-20mA current signal / ±10V DC voltage signal |
|
System Connection |
Communicate with TCCB board via JKK connector |
|
Application System |
GE Mark V Control System |
DS200PTCTG1B has been discontinued by the manufacturer.
