Brand: GE Description: TC2000 Trip Module Condition: Brand New Certificate：COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 3 Payment Term: T/T Shipping Port: ShenZhen The GE DS200TCTEG1ABA is a terminal control module whose core function is to collect field sensor signals (such as speed, temperature, vibration) and execute high-speed protection logic (such as overspeed shutdown).
|
Manufacture |
GE |
|
Model Number |
DS200TCTEG1ABA |
|
Ordering Number |
DS200TCTEG1ABA |
|
Catalog |
- |
|
Country Of Origin |
USA |
|
HS CODE |
85389091 |
|
Dimension |
18cm*15cm*5cm |
|
Packing Dimension |
20cm*17cm*7cm |
|
Weight |
0.8kg |
Operating Parameters
Ambient Temperature: 0°C to 60°C
Storage Temperature Range: -40°C to 85°C
Humidity: Operates in a non-condensing environment with a relative humidity of 5% to 95%.
Supply Voltage: 24V DC.
High Level Voltage: Typically between 2V and 5V.
Low Level Voltage: Between 0V and 0.8V.
Analog Input: The GE DS200TCTEG1ABA can read 0V to 10V or 4mA to 20mA current loop signals.
Core functions
High-speed protection control: Real-time monitoring of speed signal, triggering shutdown protection when overspeed (response time ≤2ms) to prevent equipment damage.
Multi-protocol communication: Supports EtherNet/IP, Profinet, EtherCAT, and seamless integration with PLC/DCS.
Self-diagnosis and redundancy: Built-in fault diagnosis circuit (LED status indication), supports dual-network redundant communication to improve reliability.
Working principle
Signal acquisition: Sensor signal → module input terminal → signal conditioning (filtering/amplification) → ADC conversion → microprocessor logic processing.
Protection execution: If overspeed/vibration is detected, the relay output is immediately triggered to cut off the power source, and the alarm is reported through the network.
