GE IC200ETM001

Technical Parameter

Operating voltage: 5 V DC power supply.

Connector type: 26-pin connector.

Number of connectors: 16-pin serial port connector.

Operating temperature: - 20°C to 60°C.

Storage temperature: - 40°C to 85°C.

Operating humidity: 5% to 95% (non-condensing).

Functional Characteristics

Connector Design: GE IC200ETM001 has a 26-pin female connector for attachment to the expansion receiver module. There is a 16-pin serial port connector (male) in the upper left of the module; this is a serial programming port to upload firmware updates to the neighbouring Network Interface Unit (NIU).

Data Transmission: GE IC200ETM001 provides a high-speed expansion interface to achieve a data rate of 250 bits/second up to the maximum length of the expansion cable. However, if the total length is less than 250 meters and there are no ERM002 modules in the system, the data rate can be set to 1 Mbit/second. On an NIU I/O station, on the other hand, the data rate stays at the regularly set standard of 250 kbits.

Reliable Performance：GE IC200ETM001 has supply and communication monitoring mechanism reliable. The LED indicators can quickly and accurately indicate the power supply and communication state of the module, which is convenient for fault detection and can ensure the stable operation of the system. Finally, the module's performance has been validated and operated in harsh industrial environments with high reliability and stability.

Fault Diagnosis

Error Codes and Messages： The VersaMax system has built-in diagnostic functions that can monitor the working status of GE IC200ETM001 in real time. Upon fault in the system, it is capable of producing respective error codes and alarm messages. With these error codes and messages, users can then rapidly pinpoint and dissect the fault location and cause with the diagnostic software or programming tool.

Firmware updates and maintenance: by regularly upgrading the firmware of the IC200ETM001, the performance and stability of the module can be improved and some potential bugs and faults can be fixed. The module has a 16-pin serial port connector for firmware updates so that the module always stays in the best working condition.

Application Fields

Industrial automation: GE IC200ETM001 can be used in industrial automation production lines such as automobile manufacturing, mechanical processing and chemical production, to expand the control system to meet the needs of a large number of I/O points and complex control logic. The communication protocols facilitate two-way data transfer between the PLC and connected devices, ensuring timely data exchange for effective process control.

Building Automation: It is used to extend building automation systems to enable interaction with hundreds of building equipment, such as air conditioning, elevators, lighting systems, and security systems. The building's energy can be saved and comfort and safety in the building can be improved by the management of these equipment.

Power Generation and Distribution: GE IC200ETM001 is useful is in power generation and distribution, with it enabling connection to a range of devices, including monitoring devices, power generation, circuit breakers, transformers and communication devices, integrated into a system. It allows the stability and reliability of power supply trough seamless real-time monitoring and control on power system, and to ensures safe operation of power grid.
