Brand: GE Description: Analog Input Module Condition: Brand New Certificate：COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 8 Payment Term: T/T Shipping Port: ShenZhen GE IC641SUG716 helps automation systems operate smoothly, providing maximum performance and real-time control, even in the most challenging conditions, and it supports several types of industrial communication protocols with a variety of input/output configurations.
|
Manufacture |
GE |
|
Model Number |
IC641SUG716 |
|
Ordering Number |
IC641SUG716 |
|
Catalog |
90-70 |
|
Country Of Origin |
USA |
|
HS CODE |
85389091 |
|
Dimension |
9cm x 9cm x 1.5cm |
|
Packing Dimension |
11cm x 11cm x 3cm |
|
Weight |
0.4kg |
Technical Parameter
Protocol: TCP/IP Ethernet.
Data Transfer Rate: 10/100 Mbps auto-negotiation.
Power Supply Voltage: 24 VDC.
Power Consumption: less than 5 watts.
Operating Temperature: 0°C to 60°C.
Storage Temperature: -20°C to 80°C.
Humidity: 5% to 95% non-condensing.
Functional Characteristics
High Data Rate: GE IC641SUG716 has high communication rate, which is an essential requirement of real-time data transmission and control in industrial automation systems. Sending and receiving large magnitudes of data quickly, it ensures the efficient running of the system by sending I/O status data, control commands, and process parameter data.
Ethernet Communication Ability: GE IC641SUG716 can use TCP/IP Ethernet communication protocol, allowing PLC system to be connected to other devices in the local area network or wide area network. It can be effectively integrated into the current Ethernet network infrastructure, enabling an effortless connection and exchange of data among the PLC and other smart devices like computers, HMI and other PLCs.
Ease of Configuration and Management: GE's programming software makes it easy to configure and manage. The users can set up various communication parameters such as IP address, subnet mask, gateway, etc. as well as monitoring communication status and module data traffic in real time. In addition, the software offers diagnostic and troubleshooting capabilities to assist users in rapidly diagnosing and resolving issues.
Fault Diagnosis
Substitute Method: Replace suspect fault GE IC641SUG716, test with normal module. If the system starts working as expected after replacing the module, you will get to know that its the original one which has gone bad and needs to be replaced or repaired.
Ping Test: Check network connection between module and other devices using the Ping command If the Ping test fails, it means that the network connection may have a problem, and the network cable, router, switch and other network equipment should be further checked to ensure the network operates normally.
Application Fields
Industrial Automation: GE IC641SUG716 is used for connecting and managing a large number of I/O devices in industrial automation production lines such as automotive manufacturing, food processing, and packaging machinery.
Process Control: In the process control industry, such as chemical, petrochemical and pharmaceutical industries, GE IC641SUG716 can be used to connect sensors, actuators, and other equipment, transmit analog and digital signals, and help realize the precise control of process parameters such as temperature, pressure, and flow.
Building Automation: It can be used in building automation systems to connect and control various devices such as air conditioners, elevators, lighting systems, realize the centralized management and intelligent control of buildings, and improve the comfort and energy efficiency of buildings.
Power System: GE IC641SUG716 can be used to connect and monitor various power generators, transformers, transmission/distribution equipment and sensors in the power generation, transmission system and distribution process and upload the collected data to the control center through the device for real-time monitoring and control of the power system.
