Brand: GE Description: Input Module Condition: Brand New Certificate：COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 7 Payment Term: T/T Shipping Port: ShenZhen GE IC694MDL646 is capable of handling a wide range of applications that require precise and reliable digital signal control. It supports both sinking and sourcing types of output, offering flexibility for various control needs.
|
Manufacture |
GE |
|
Model Number |
IC694MDL646 |
|
Ordering Number |
IC694MDL646 |
|
Catalog |
RX3i |
|
Country Of Origin |
USA |
|
HS CODE |
85389091 |
|
Dimension |
12cm x 7cm x 3.5cm |
|
Packing Dimension |
15cm x 10cm x 6cm |
|
Weight |
0.8kg |
Technical Parameter
Rated Voltage: 24 VDC.
Input Voltage Range: 0 to +30 VDC
Number of Inputs: 16.
Input Current: 7 mA.
On-State Voltage: 11.5 to 30 VDC.
Off-State Voltage: 0 to +5 VDC.
On-State Current: 3.2 mA minimum.
Off-State Current: 1.1 mA maximum.
On/Off Response Time: 1 ms.
Operating Temperature Range: 0 to 60 °C.
Storage Temperature Range: -40 to 85 °C.
Functional Characteristics
Response Time: The on and off response times for GE IC694MDL646 are generally 1 msec, providing real time and accurate acquisition of the input signals which is a must for applications with high-speed control requirements.
Low Power Consumption: Low power consumption is consumed by 80mA from 5V bus and 125mA from 24V also in favor of low power consumption making system low power consumption and improving energy efficiency.
Isolation Protection: GE IC694MDL646 has field to backplane and to frame ground isolation. The isolation voltage is 250V AC continuous and 1500V AC for one minute, providing reliable electrical isolation and protecting the module and the system from electrical interference and damage.
Fault Diagnosis
Voltage and Current Measurement: Input voltage flow experimental test of GE IC694MDL646 uses a multimeter to measure If these readings are already out of the normal range, it indicates a problem with the power supply or the module's internal circuitry.
LED Indicator: Each input point can display the status of each input with LED indicators. Users are very easy to determine whether the input signal normal, and the module work normally by observing the status of the LED.
Application Fields
Industrial Automation: GE IC694MDL646 is widely used in various industrial automation production lines, including automotive manufacturing, food processing and pharmaceutical production, for monitoring the status of sensors, switches and other devices, and realizing the control and monitoring of the production process.
Power System: In the fields of power generation, transmission and distribution systems, it can be used to monitor the state of circuit breakers, relays and other equipment, timely transmission status information to the control system, improve the power system safe and stable operation.
Building Automation: In building automation systems, GE IC694MDL646 can monitor the status of various sensors and switches of the building (temperature sensor, light sensor, door sensor) and control the operation of air conditioning systems, lighting system and access control systems.
Transportation: It can be applied to the control system of railways, subways, intelligent transportation systems, and other application scenarios, which can monitor the state of the signals, switches, and other equipment and ensure the safety and efficiency of the transportation system.
