GE IC697PWR720

Brand: GE
Description: Power Supply Adapter module
Condition: Brand New
Certificate:COO TEST REPORT WARRANTY LETTER
Warranty: 1 year
Inventory Qty: 13
Payment Term: T/T
Shipping Port: ShenZhen
GE IC697PWR720 is a power adapter designed for the 90-70 Series PLC systems. It provides regulated output voltages of +5 VDC, +12 VDC, and -12 VDC from a 24 VDC input. It ensures that power is properly distributed to the PLC's backplane and connected modules.

Send Inquiry

Product Description

Manufacture
GE
Model Number
IC697PWR720
Ordering Number
IC697PWR720
Catalog
90-70
Country Of Origin
USA
HS CODE
85389091
Dimension
13cm x 7cm x 4.5cm
Packing Dimension
15cm x 9cm x 7cm
Weight
0.8kg
Operating Parameters

Input Voltage:Nominal 24 VDC

Range: +21 VDC to +32 VDC

Output Voltage: +5 VDC (Regulated) +12 VDC (Regulated) -12 VDC (Regulated)

Power Handling:Maximum Input Power: 156 Watts

Output Power: 90 Watts

Input Current:Draws approximately 6.5 A from the 24 VDC input source.

Output Current: +5 VDC: 10 A (maximum +12 VDC: 1 A (maximum) -12 VDC: 1 A (maximum)

Ripple and Noise:+5 VDC Output: <50 mV peak-to-peak

+12 VDC and -12 VDC Outputs: <100 mV peak-to-peak


Product Features

Overvoltage Protection:Preventing overvoltage damage to the power supply and connected modules by integrating overvoltage protection.

Short-Circuit Protection:Built-in short circuit protection protects the power supply from damage due to any short in the connected load.

Overcurrent Protection:Integrated overcurrent protection is provided for each output, preventing the output current from exceeding a safe value that might damage either the power supply or other system components.

Thermal Shutdown:Power supply has thermal protection which can shutdown the unit by overheating.

Stabilized Output: The module includes optimized voltage regulation methods. GE IC697PWR720 is able to regulate the output voltage even with a change in the input voltage or a change in load. This steady output is important for sensitive electronic parts that need constant power for accurate operation.

LED Status Indicators: GE IC697PWR720 has clear LED indicators that show the operating status of the power supply. For instance, a green LED may represent normal operation, red LED may indicate a fault or some abnormal condition, which can help technicians quickly identify the operational state of the system visually.


Installation

Mechanical Installation:The GE IC697PWR720 is intended for installation in standard industrial racks. It includes chakra adaptable, rack file formats and brackets.Consider a flatbar or two to help push it in all the way, and be sure to use the right screws to hold it in, you don't want it to work loose over time (and likely due to vibration).

Electrical Installation: When connecting the power input cables, follow the provided wiring diagrams carefully. Use proper cable gauges to handle the current load. For the output connections, make sure to connect the correct polarity to the receiving devices. It is advisable to use terminal blocks or connectors that provide a secure and reliable connection.

Installation Environment: Make sure to install the module in an environment with appropriate temperature and humidity level compatible to the module. Usually, it is supposed to work within a temperate range of -20° to +60° and a relative humid range of 5% to 95% (non-condensing). Do not use in dusty, corrosive gas environment, strong electromagnetic field environment.


Application Range

Industrial Control Systems: In factories, GE IC697PWR720 powers Programmable Logic Controllers,such as, Programmable Logic Controllers (PLCs), input/output modules, control components, etc. It facilitates the smooth running of automated production lines by offering a stable source of energy.

Robotics and Automation Cells: GE IC697PWR720 provides the required power for robotic arms, automated guided vehicles (AGVs), and other robotic systems. Stable voltage output is provided so that the moving parts can work accurately to operate these machines properly.

Process Control Applications: Used in industries like chemical, pharmaceutical, and food processing that require precise control of equipment, it powers sensors, actuators, and controllers. It reusable makes sure for stability and accuracy in the process in production.


Troubleshooting

No Power Output:Ensure the external power supply is within +21 VDC to +32 VDC range.Inspect all the connections to confirm they are properly attached and configured. Check the status LEDs on adapter for fault conditions.

Overvoltage Protection Activation:If the adapter has overvoltage protection, once the input voltage exceeds the prescribed range, out of range inputs will shut down outputs. Test vaporizer boards— Ensure voltage applied on input is within the permissible limit And if there is overvoltage condition, first bringing it to normal and then reset the system.

Insufficient Power Distribution:Make sure the total power requirement of the connected modules does not exceed the adapter power output capacity. Inspect the connected modules for any short circuits or faults that might be causing high current draw.
