Brand: GE Description: IS200DAMDG1AAA Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 13 Payment Term: T/T Shipping Port: Shenzhen GE IS200DAMDG1AAA Provides consolidated analog and discrete drive signals for governor and auxiliary control valves in gas-turbine and engine-generator applications.
|
Manufacture |
GE |
|
Model Number |
IS200DAMDG1A |
|
Ordering Number |
IS200DAMDG1AAA |
|
Catalog |
531X |
|
Description |
GE IS200DAMDG1AAA Gate Driver Board |
|
Country Of Origin |
USA |
|
HS CODE |
8479909090 |
|
Dimension |
233 × 160 × 50 mm |
|
Weight |
0.56 kg |
Technical Parameters
Analog Outputs:
8 channels, 4–20 mA loop-powered or 0–10 V (jumper-selectable) for the GE IS200DAMDG1AAA
16-bit DAC resolution; ± 0.05 % full-scale accuracy
Update rate: 500 updates/sec per channel
Short-circuit and open-circuit detection
Discrete Outputs:
8 open-collector driver channels, 24 V DC, 0.1–2 A per channel
Turn-on ≤ 5 ms; turn-off ≤ 3 ms
Per-channel load-OK sensing and fault reporting by GE IS200DAMDG1AAA
Isolation: Reinforced channel-to-channel and channel-to-ground (> 1 kV)
Connectors:
Dual 50-pin I/O-pack backplane edge connectors
52-position right-angle pluggable terminal block for field wiring
Environmental:
Operating: –30 °C to +65 °C
Storage: –40 °C to +85 °C
Humidity: up to 95 % RH, non-condensing
Product function
Translates digital governor commands into precise analog drive signals through the GE IS200DAMDG1AAA while simultaneously issuing discrete enable/inhibit and interlock commands. Built-in diagnostics continuously monitor output loops and loads, reporting any anomalies to the Mark VIe CPU for immediate corrective or protective action.
Core supporting modules
I/O Pack Carrier: IS42xPSCAH1B power/carrier assembly (provides 24 V DC and IONet connectivity)
Controller Module: IS200TPROH1C Mark VIe CPU executing governor and safety logic for GE IS200DAMDG1AAA
Position Feedback Pack: IS215UCVGM06A providing valve-position feedback loops
Extension components
Pluggable Terminal Blocks: Screw-clamp blocks keyed for analog vs. discrete channels
DIN-Rail/Panel Mount Kits: Adapter clips for 35 mm rail or panel installation
Shielding Accessories: Cable-shield clamps for EMI suppression
Calibration Fixtures: External loop calibrators for GE IS200DAMDG1AAA analog outputs
Software support
Configuration & Calibration:
Output-mode settings defined via GE ToolboxST™ templates for GE IS200DAMDG1AAA
On-line calibration wizards for analog spans
Diagnostics & Monitoring:
Real-time load-OK flags accessible in HMI tags
Self-test at power-up with diagnostic flags recorded
Firmware Updates: Delivered as part of Mark VIe system releases
Documentation: Detailed in GE Mark VIe/VIeS I/O Guide and Multi-Driver Governor Module Reference Manual
