GE IS200DAMEG1A

Technical Parameters

Analog Outputs:

8 × 4-20 mA current-loop outputs (jumper-selectable for 0-10 V) for the GE IS200DAMEG1A

16-bit DAC resolution, ± 0.05 % FS accuracy

Update rate: 500 updates/sec per channel

Built-in short-circuit and open-circuit detection

Digital Inputs:

8 × 24 V DC discrete inputs with 4 ms debounce

Input current: 2.5 mA nominal; overvoltage/clamp protection to ± 35 V

Isolation:

Reinforced channel-to-channel and channel-to-ground (> 1 kV)

Connectors:

Dual 50-pin backplane edge connectors

Right-angle 34-way pluggable terminal block for field wiring

Environmental:

Operating Temp: -30 °C to +65 °C

Storage Temp: -40 °C to +85 °C

Humidity: up to 95 % RH, non-condensing

Product function

Governor Signal Generation: Digitally controlled analog outputs deliver precise speed/load setpoints through the GE IS200DAMEG1A to engine-governor valves.

Status Monitoring: Discrete inputs capture critical governor-system statuses such as overspeed trips, mode selects, and manual overrides.

Diagnostics: On-board detection of loop faults (open, short) and discrete-input errors, reported back to the Mark VIe CPU for alarms and safe-state actions.

Core supporting modules

I/O Pack Carrier: IS42xPSCAH1B supplying 24 V DC power and IONet backplane connectivity

Controller Module: IS200TPROH1C Mark VIe CPU executing governor algorithms and safety interlocks

Valve-Drive Pack: IS215UCVDH7AM Universal Control-Valve Drive Module for complementing analog output drives

Extension components

Pluggable Terminal Blocks: 34-way screw-clamp blocks keyed for analog/digital segregation, with shield-termination posts

DIN-Rail & Panel-Mount Kits: Adapter clips and brackets for 35 mm rail or enclosure-panel installation

Shielding Accessories: Cable-shield clamps and ferrite cores for EMI suppression on analog loops and digital wiring

Calibration Fixtures: Precision loop calibrators for GE IS200DAMEG1A analog channels

Software support

Configuration & Calibration:

Output-range selection, filter constants, and discrete-input logic configured via GE ToolboxST™ templates

On-line calibration wizard for analog spans and digital-input thresholds

Diagnostics & Monitoring:

Real-time loop-health, open/short status, and input-fault flags accessible in HMI, OPC-DA tags, and controller diagnostics

Sequence-of-events logging for discrete-input transitions

Firmware Updates: Delivered as part of Mark VIe system releases; applied through ToolboxST™ with CRC validation and rollback

Documentation: Detailed procedures in the GE Mark VIe/VIeS I/O Installation Guide and the Engine-Governor Module Reference Manual for GE IS200DAMEG1A
