GE IS200DSFCG1AEB

Working Voltage: 18 - 36V DC.

Input Signals Types: 5V and 10V DC from all sorts of transmitters.

Types of Output Signals: 0 – 20 mA and 0 – 200 mA analog current output.

Terminal Capacity: 3.0 mm².

Minimum Screw Pitch: 5.08 mm (0.2 inches).

Ethernet interface — Communication interface.

Temperature range of operation: 0°C to 65°C.

Product Features

Diverse Signal Handling: To handle different signals, GE IS200DSFCG1AEB is suitable. It can receive a voltage input from bus and generator through two built - in potential transformers (PTs). At the same time, it can process the conditional speed signal input of I/O packages (which is key for accurately monitoring and controlling the parameters associated with turbine systems speed).

Redundant Protection Design: The board is designed with backup protection in Mark VIe or Mark VleS control systems. It completes backup protection together with PPRO or YPRO by connecting to the relay board. It provides redundancy with the design of the whole control system and ensures its reliability and safety, such that the system can still function correctly after the prime protection fails.

Features Multi-Function Analog I/O: It is capable of accepting different forms of analog input and output signals. For the analog input, it supports two - wire, three - wire and four - wire transmitters and externally powered transmitters, and input voltage of 5V and 10V DC. It has 0 - 20 mA and 0 - 200 mA current output options for analog output which can meet the demands of signal transmission and control of analog signals in the industrial sector.

Installation

DIN Rail Installation: GE IS200DSFCG1AEB is a metal plate carrier that can be installed on a DIN rail. Make sure that the DIN rail is fixed and grounded properly. Next, fit the metal plate carrier over the DIN rail and slide it until it clicks into latch mode.

Troubleshooting

Signal Input Failure: Check whether the connection wires are loose, broken, or short - circuited in case of abnormal speed signal or voltage input. Check the status of the sensors and PTs giving the input signals.

Output Signal Abnormality: The analog output signal is empty or fluctuates; try to detect the output connection of the cable and the connected device is normal. Ensure that the output signal configuration settings on the board is correct.

Communication Problem: Verify Proper Cable Connection: In the event of communication failure between GE IS200DSFCG1AEB and other devices within the control system, check the Ethernet cable connection to determine whether they are firmly plugged in and if they are damaged or not. Ensure the communication parameters of the board and the connected devices (IP address / subnet mask / gateway) match. If the communication failure cannot be solved by the methods above, it is mostly because there is a fault in the communication interface or software of the board, further debug and troubleshooting need to be performed.

Application range

Gas turbine power generation system: GE IS200DSFCG1AEB monitor the gas turbine speed and voltage, etc. It is responsible for the stable operation of gas turbines and the optimization of power generation efficiency, and is an important guarantee for the safety and reliability of the entire power generation process.

Steam Turbine Monitoring: GE IS200DSFCG1AEB is used in steam turbine units for processing speed signal and voltage input, and is involved with steam turbine regulation and steam turbine protection. It serves as a vital system to accurately control the rotating speed of steam turbines and monitor the voltage status, thus ensuring a proper and stable operation of steam turbines in power plants.

Industrial Automation Systems: Whether processing signals for control or protection in automated production processes, these signals can be sent in discrete signal architecture whenever precise control of an element is of concern. It orchestrates other components to enable the automation and intelligentization of production, leading to enhanced production efficiency and better product quality.
