Brand: GE Description: Exciter De-Excitation Control Board Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 5 Payment Term: T/T Shipping Port: ShenZhen GE IS200EDEXG1BAA is an exciter de-excitation control board. Its primary function is to safely dissipate the energy stored in the generator field inductance during de-excitation, ensuring a smooth and controlled shutdown of the generator.
Manufacture |
GE |
Model Number |
IS200EDEXG1BAA |
Ordering Number |
IS200EDEXG1BAA |
Catalog |
Mark VI |
Country Of Origin |
USA |
HS CODE |
8479909090 |
Dimension |
40cm*20cm*6cm |
Packing Dimension |
42cm*22cm*8cm |
Weight |
1.5kg |
Operating Parameters
Power Supply: 24V DC power supply.
Temperature Range: - 20°C to 60°C.
Humidity Tolerance: The module can withstand relative humidity levels up to 95% non - condensing.
Protocol Support: It supports common industrial communication protocols like Modbus RTU.
Data Transfer Rate: The data transfer rate is configurable, with typical rates ranging from 9600 to 115200 baud.
Communication Protocol: Supports high-speed communication protocols such as Ethernet for seamless integration with other control systems.
Environmental Protection: Built to withstand harsh industrial environments, including resistance to vibration, humidity, and electromagnetic interference.
Product Functions
Dissipation of Stored Energy During De-Excitation: The module dissipates the stored energy of the generator field inductance during de-excitation, thus ensuring safe shutdown of the generator.
SCR Firing: GE IS200EDEXG1BAA handles the firing sequence of the SCRs that enable properly controlled de-excitation.
De-Excitation Feedback: GE IS200EDEXG1BAA is relevant because the module provides conduction sense feedback that is free of the link degradation for de-excitation.
Voltage Retention: GE IS200EDEXG1BAA maintains voltage in the event of a power failure, allowing for uninterrupted use.
Excitation Control: Regulates field current of the generator to maintain a constant voltage output.
Signal Processing: Handles input signals from the sensors and control modules to determine proper responses from the system.
Anomaly Detection: GE IS200EDEXG1BAA enables to keep track of system efficiency and identify errors in real-time.
Communication Interface: This interfaces for transmitting data from excitation system with other control units within the Mark VIe platform.
Redundancy Support: Capable of providing redundant setups for increased system redundancy.
Application Scope
Power Generation Plants: Control of generator excitation systems for stable and efficient generation of electric power.
Industrial Automation: Designed to offer robust control and communication for complex industrial processes where reliable excitation control is essential.
Troubleshooting
Signal Transmission Problems: If you experience signal transmission issues, check all connections to ensure that they are tight and that the cables are not damaged. Check the terminal boards and verify that there are no faults with the module connected.
SCR Allumination Firing errors: For SCR not firing correctly, check control signals coming from EMIO and EXTB boards. Check for firing signals to the GE IS200EDEXG1BAA module and that the SCRs are not defective.
