Brand: GE Description: IS200JPDCG1ACB Condition: Brand New Certificate: COO TEST REPORT WARRANTY LETTER Warranty: 1 year Inventory Qty: 18 Payment Term: T/T Shipping Port: Shenzhen GE IS200JPDCG1ACB Installed in the DC power-distribution shelf of a Mark VIe/VIeS control cabinet, the IS200JPDCG1ACB redundantly supplies and monitors both “control” and “wetting” voltages to downstream I/O and logic modules.
|
Manufacture |
GE |
|
Model Number |
IS200JPDCG1ACB |
|
Ordering Number |
IS200JPDCG1ACB |
|
Catalog |
Mark VI |
|
Description |
GE IS200JPDCG1ACB Power Distribution Module |
|
Country Of Origin |
USA |
|
HS CODE |
8537101190 |
|
Dimension |
233 × 37 × 160 mm |
|
Weight |
0.82 kg |
Technical Parameters
Input Voltage: 28 V DC nominal (27.4–28.6 V DC)
Redundant Supplies: Dual diode-OR'd inputs for true 1-out-2 redundancy
Output Circuits:
Control Power: 28 V DC at board-rated load
Wetting Power: 24 V DC at up to 3 mA per contact-input pack
Diagnostics Interface: 50-pin P2 connector to IS220PPDAH1A feedback module
Status LEDs: 8 × board-ID and live-circuit health indicators
Conformal Coating: Class B for enhanced moisture and contaminant resistance
Environmental Ratings:
Operating: –30 °C to +65 °C
Storage: –40 °C to +85 °C
Humidity: up to 95 % RH, non-condensing
Product function
The GE IS200JPDCG1ACB delivers redundant DC control and wetting voltages to all I/O packs and terminal boards, while aggregating AC-sense and DC-sense diagnostics for the PPDA feedback module. Ensures continuous, monitored power-system operation by triggering alarms or automatic transfers in the event of supply faults.
Core supporting modules
Feedback Module: IS220PPDAH1A Power-Distribution Feedback Pack (connected to GE IS200JPDCG1ACB)
I/O Pack Carrier: IS42xPSCAH1B Power/Carrier Assembly
Controller: GE Mark VIe CPU (e.g., IS200TPROH1C) for power-health monitoring and HMI display
Extension components
Ribbon Jumpers: 50-pin keyed jumpers for P2-to-P1 interconnect (used with GE IS200JPDCG1ACB)
Mounting Hardware: Screw-standoffs and bracket kit for chassis installation
DIN-Rail Adapters: Clips for 35 mm rail mounting in retrofit racks
Spare LEDs: Replacement ID and status-indicator LED assemblies (for GE IS200JPDCG1ACB)
Software support
Configuration: Automatic board-ID mapping; no user setup required (GE IS200JPDCG1ACB)
Diagnostics & Monitoring:
Real-time DC-sense and AC-sense alarms visible in GE ControlST™/ToolboxST™ and via OPC-DA tags
Fault counters and status flags reported through controller diagnostics
Firmware: Not applicable—fully hardware-based functionality
Documentation: Covered in the GE Mark VIe/VIeS Power-Distribution Feedback Module Manual and the I/O Installation Guide
